Запчасти Komatsu GD530A ДВИГАТЕЛЬ ЭЛЕКТРОПРОВОДКА ЭЛЕКТР.

1

ALTERNATOR - MODEL 23SI (SEE PG 08-032)

-29шт.

1

ALTERNATOR - MODEL 20SI (SEE PG 08-034)

-29шт.

1

ALTERNATOR - MODEL 30SI (SEE PG 08-038)

-29шт.

1

ALTERNATOR - MODEL 26SI (SEE PG 08-042)

-29шт.

2

SENDING UNIT, ENGINE WATER TEMP. (SEE PG 08-076)

-29шт.

3

1437 619 H94

HARNESS, ENGINE WIRING

1шт.

4

299 407 C1

CLAMP, CABLE

1шт.

|$7

299 404 C1

CLAMP, CLOSED

1шт.

5

299 614 C1

CLAMP, CABLE

1шт.

|$9

30 041 R1

BOLT

2шт.

|$10

25 536 R1

WASHER, FLAT

4шт.

6

ELBOW, SPECIAL - 90 DEGREES (SEE PG 08-076)

-29шт.

7

MOTOR, CRANKING (SEE PG 08-026)

-29шт.

|$13

30 976 R1

SCREW

3шт.

8

SWITCH, CLUTCH PRESSURE (SEE PG 08-076)

-29шт.

9

MAIN WIRING HARNESS - TO REAR (SEE PG 08-006)

-29шт.

10

141 453 H1

CLAMP, CABLE

2шт.

|$17

25 536 R1

WASHER, FLAT

2шт.

11

1437 824 H93

HARNESS, MAIN WIRING

1шт.

12

130 096

CLAMP, CABLE

1шт.

|$20

105 899

STUD, WELD

1шт.

|$21

25 534 R1

WASHER, FLAT

1шт.

|$22

25 522 R1

NUT, HEX

1шт.

13

FILTER, CONVERTER OIL (SEE PG 07-014)

-29шт.

14

143 142 H1

CLAMP, CABLE

1шт.

15

1207 387 H2

SWITCH, MAGNETIC

1шт.

|$26

28 448 R1

BOLT

2шт.

|$27

120 392

WASHER, FLAT

2шт.

|$28

25 519 R1

NUT, HEX

2шт.

16

1434 203 H1

DIODE

1шт.

17

SENDING UNIT, ENGINE OIL PRESSURE (SEE PG 08-076)

-29шт.

18

1137 360 C2

SWITCH, ENGINE WATER TEMPERATURE

1шт.

19

299 565 C1

CLAMP, CABLE

4шт.

|$33

136 055

CLAMP, CABLE

6шт.

|$34

105 899

STUD, WELD

10шт.

|$35

25 534 R1

WASHER, FLAT

17шт.

|$36

25 522 R1

NUT, HEX

14шт.

20

299 399 C1

CLAMP, CABLE

1шт.

|$38

37 467

STUD, WELD

3шт.

|$39

25 532 R1

WASHER, FLAT

9шт.

|$40

25 519 R1

NUT, HEX

9шт.

21

SENDING UNIT, ARTICULATION (SEE PG 08-078)

-29шт.

|$44

-1шт.

|$43

-1шт.
