Запчасти Komatsu GD530A СДВОЕНН. ПРИВОД MACHINES БЕЗ PLANETARY КОНЕЧНАЯ ПЕРЕДАЧА ПРИВОД TRAIN

|$0

1283 326 H92

AXLE ASSEMBLY

a

1шт.

|$1

1431 178 H91

AXLE ASSEMBLY

b

1шт.

1

19 940 R1

NUT, LOCK

4шт.

2

1432 377 H1

WASHER

4шт.

3

WHEEL (SEE PG 15-002)

-29шт.

4

1431 923 H1

GASKET

4шт.

5

130 216

KEY

4шт.

6

24 862 R1

BOLT

24шт.

7

25 536 R1

WASHER, FLAT

24шт.

8

12 353

RETAINER, BEARING

4шт.

9

47 164

SHIM - 0.030 IN. (0.762 MM) - CORAL

-2шт.

|$11

47 164 AH45

SHIM - 0.015 IN. (0.381 MM) - PINK

-2шт.

|$12

47 164 B

SHIM - 0.005 IN. (0.127 MM) - BLUE

-2шт.

|$13

1285 283 H1

SHIM - 0.003 IN. (0.076 MM) - GREEN

-2шт.

|$14

1285 284 H1

SHIM - 0.002 IN. (0.050 MM) - RED

-2шт.

10

1278 105 H1

SEAL, OIL

4шт.

11

24 862 R1

BOLT

48шт.

12

25 536 R1

WASHER, FLAT

48шт.

13

1283 506 H92

HOUSING, BEARING

4шт.

14

159 907

KIT, LIQUID GASKET

1шт.

|$20

NSS

NO. 518 GASKET - 25 ML SYRINGE

1шт.

|$21

NSS

PRIMER N - 40 GRAM CAN

1шт.

15

619 697 C1

CUP, BEARING

8шт.

16

619 696 C91

CONE, BEARING

8шт.

17

1432 375 H91

SHAFT WELDMENT, REAR - 45 TEETH

2шт.

18

1432 376 H91

SHAFT WELDMENT, FRONT - 45 TEETH

2шт.

19

1438 386 H91

CHAIN - DOUBLE STRAND

4шт.

20

79 491

LINK, CONNECTING

1шт.

|$28

54 813

LINK, ROLLER

-2шт.

21

1285 653 H1

COVER, ACCESS

4шт.

22

25 534 R1

WASHER, FLAT

16шт.

23

140 483 H

BOLT

16шт.

24

24 860 R1

BOLT

16шт.

25

25 536 R1

WASHER, FLAT

16шт.

26

68 363

COVER, ACCESS

8шт.

27

33 603

BREATHER VALVE ASSEMBLY

2шт.

28

23 921 R1

BUSHING, REDUCER

2шт.

29

1277 938 H1

ADAPTER, PIPE

2шт.

30

280 668 R91

PLUG, MAGNETIC

a

4шт.

30

89 946

PLUG, MAGNETIC

b

4шт.

|$40

1436 098 H91

CASE, TANDEM WELDMENT

2шт.

31

1283 594 H91

CASE, TANDEM

1шт.

32

1430 117 H1

STEP, UPPER

1шт.

33

1430 116 H1

STEP, LOWER

1шт.

34

444 687

PLUG, PIPE - 1/8 IN. NPT

2шт.

35

77 506

BREATHER

2шт.

36

83 005 H45

PLUG, PIPE - 1 IN. NPT

2шт.

N/I

634 016 C1

PIPE SEALANT - 50 ML

1шт.

|$63

-1шт.

|$49

F1 - QUANTITIES ARE FOR 2 TANDEM CASE.

-1шт.

|$64

-1шт.

|$65

-1шт.

|$52

F2 - NOT USED ON CURRENT PRODUCTION MACHINES: SERIAL NUMBER BREAK

-1шт.

|$53

UNKNOWN. USE ITEM 35 INSTEAD.

-1шт.

|$66

-1шт.

|$55

F3 - NO LONGER USED ON CURRENT PRODUCTION MACHINES: SERIAL NUMBER

-1шт.

|$56

BREAK UNKNOWN.

-1шт.

|$67

-1шт.

|$58

F4 - USED INSTEAD OF ITEMS 27, 28, AND 29 ON CURRENT PRODUCTION

-1шт.

|$59

MACHINES ONLY: SERIAL NUMBER BREAK UNKNOWN.

-1шт.

|$68

-1шт.

|$61

F5 - USED ON CURRENT PRODUCTION MACHINES ONLY: SERIAL NUMBER BREAK

-1шт.

|$62

UNKNOWN.

-1шт.
