Запчасти Komatsu GD530A ВХОД QUILL ASSEMBLY ПРИВОД TRAIN

|$0

CASE ASSEMBLY, DIFFERENTIAL (SEE PG 07-056)

1шт.

|$1

107 578 R91

BEARING ASSEMBLY

1шт.

1

107 579 R91

BEARING, CONE

1шт.

2

107 580 R1

BEARING, CUP

1шт.

3

149 892

SHIM - 0.003 IN. (0.076 MM)

-2шт.

|$5

149 891

SHIM - 0.005 IN. (0.127 MM)

-2шт.

|$6

149 893

SHIM - 0.010 IN. (0.254 MM)

-2шт.

4

1431 835 H1

COVER, DIFFERENTIAL CASE

1шт.

5

1430 195 H1

SHIM

-2шт.

|$9

1430 196 H1

SHIM

-2шт.

|$10

1430 197 H1

SHIM

-2шт.

|$11

1430 198 H1

SHIM

-2шт.

6

1430 150 H1

SPACER

1шт.

|$13

107 575 R91

BEARING ASSEMBLY

1шт.

7

107 577 R1

BEARING, CUP

1шт.

8

107 576 R91

BEARING, CONE

1шт.

|$16

1430 410 H91

KIT, YOKE AND SEAL

1шт.

|$17

1438 078 H91

KIT, YOKE AND SEAL

1шт.

9

1430 207 H1

YOKE

1шт.

|$19

1430 411 H91

KIT, SEAL

1шт.

10

1430 149 H91

SEAL

1шт.

11

1430 208 H1

V-SEAL

1шт.

12

22 288 R1

O-RING

1шт.

13

149 899

WASHER, SPECIAL

-2шт.

|$24

149 900

WASHER, SPECIAL

-2шт.

|$25

149 901

WASHER, SPECIAL

-2шт.

14

149 898

NUT, CASTLE

1шт.

15

103 411

PIN, COTTER

1шт.

|$37

-1шт.

|$29

F1 - THREE SPECIAL WASHERS AVAILABLE: BUT USE ONLY ONE (1).

-1шт.

|$38

-1шт.

|$39

-1шт.

|$32

F2 - USED WITH 1431 780 H93 (SEE PG 07-057) OR 1431 880 H93 (SEE PG 07-059)

-1шт.

|$33

FOR S/N 203163-203506.

-1шт.

|$40

-1шт.

|$35

F3 - USED WITH 1437 866 H91 (SEE PG 07-057) OR 1437 865 H91 (SEE PG 07-059)

-1шт.

|$36

FOR S/N 203507 AND UP. YOKE AND SEAL KIT IS INCLUDED.

-1шт.
