Запчасти Komatsu GD530A ТОПЛИВН. ВПРЫСК ТОПЛИВН. СИСТЕМА

Схема запчастей Komatsu GD530A - ТОПЛИВН. ВПРЫСК ТОПЛИВН. СИСТЕМА
8
4
3
1
10
9
5
6
2
7

Артикул

Название

Примечание

Количество

|$0

6733-11-3100

KIT, INJECTOR

6шт.

1

NSS

INJECTOR, FUEL

1шт.

2

6736-11-3430

SEAL, INJECTOR

1шт.

3

6732-71-6230

SEAL, BANJO CONNECTOR

1шт.

4

6732-11-3850

SEAL, RECTANGULAR RING

1шт.

5

6734-11-3610

SHIM - 0.039 IN. (1.00 MM) THICK

-2шт.

|$6

6734-11-3620

SHIM - 0.041 IN. (1.04 MM) THICK

-2шт.

|$7

6734-11-3630

SHIM - 0.042 IN. (1.08 MM) THICK

-2шт.

|$8

6734-11-3640

SHIM - 0.043 IN. (1.10 MM) THICK

-2шт.

|$9

6734-11-3650

SHIM - 0.045 IN. (1.14 MM) THICK

-2шт.

|$10

6734-11-3660

SHIM - 0.046 IN. (1.18 MM) THICK

-2шт.

|$11

6734-11-3670

SHIM - 0.047 IN. (1.20 MM) THICK

-2шт.

|$12

6734-11-3680

SHIM - 0.049 IN. (1.24 MM) THICK

-2шт.

|$13

6734-11-3690

SHIM - 0.050 IN. (1.28 MM) THICK

-2шт.

|$14

6734-11-3710

SHIM - 0.051 IN. (1.30 MM) THICK

-2шт.

|$15

6734-11-3720

SHIM - 0.053 IN. (1.34 MM) THICK

-2шт.

|$16

6734-11-3730

SHIM - 0.054 IN. (1.38 MM) THICK

-2шт.

|$17

6734-11-3740

SHIM - 0.055 IN. (1.40 MM) THICK

-2шт.

|$18

6734-11-3750

SHIM - 0.057 IN. (1.44 MM) THICK

-2шт.

|$19

6734-11-3760

SHIM - 0.058 IN. (1.48 MM) THICK

-2шт.

|$20

6734-11-3770

SHIM - 0.059 IN. (1.50 MM) THICK

-2шт.

|$21

6734-11-3780

SHIM - 0.061 IN. (1.54 MM) THICK

-2шт.

|$22

6734-11-3790

SHIM - 0.062 IN. (1.58 MM) THICK

-2шт.

|$23

6734-11-3810

SHIM - 0.063 IN. (1.60 MM) THICK

-2шт.

|$24

6734-11-3820

SHIM - 0.065 IN. (1.64 MM) THICK

-2шт.

|$25

6734-11-3830

SHIM - 0.066 IN. (1.68 MM) THICK

-2шт.

|$26

6734-11-3840

SHIM - 0.067 IN. (1.70 MM) THICK

-2шт.

|$27

6734-11-3850

SHIM - 0.069 IN. (1.74 MM) THICK

-2шт.

|$28

6734-11-3860

SHIM - 0.070 IN. (1.78 MM) THICK

-2шт.

|$29

6734-11-3870

SHIM - 0.071 IN. (1.80 MM) THICK

-2шт.

|$30

6734-11-3880

SHIM - 0.072 IN. (1.84 MM) THICK

-2шт.

|$31

6734-11-3890

SHIM - 0.074 IN. (1.88 MM) THICK

-2шт.

|$32

6734-11-3910

SHIM - 0.075 IN. (1.90 MM) THICK

-2шт.

|$33

6734-11-3920

SHIM - 0.076 IN. (1.94 MM) THICK

-2шт.

|$34

6734-11-3930

SHIM - 0.078 IN. (1.98 MM) THICK

-2шт.

6

6734-11-3160

SPRING, COMPRESSION

6шт.

7

6734-11-3180

SPINDLE

6шт.

8

6734-11-3170

DISC, INTERMEDIATE

6шт.

9

6734-11-3140

RETAINER, INJECTOR NOZZLE

6шт.

10

6735-11-3160

NOZZLE, INJECTOR

6шт.

|$43

-1шт.

|$41

R1 - REMANUFACTURED ASSEMBLY AVAILABLE: REFER TO REMANUFACTURED

-1шт.

|$42

ASSEMBLIES CATALOG.

-1шт.

Выбрано товаров: 43
