Запчасти Komatsu GD530A ШАТУН И ПОРШЕНЬ БЛОК ЦИЛИНДРОВ

|$0

6732-31-3100

ENGINE ROD ASSEMBLY

6шт.

1

NSS

ROD, ENGINE CONNECTING

1шт.

2

6732-31-3310

BOLT, CONNECTING ROD CAP - MJ11 X 1.25 X 59

2шт.

3

6732-31-3130

BUSHING

1шт.

4

6732-31-3410

BEARING, CONNECTING ROD - STD

2шт.

|$5

6735-31-2140

KIT, ENGINE PISTON - STD, COMPRESSION RATIO 17.3

6шт.

5

NSS

PISTON, ENGINE

1шт.

6

6736-31-2510

RING, RETAINING

2шт.

7

6732-31-2300

SET, PISTON RING

1шт.

8

6736-31-2420

PIN, PISTON

6шт.

|$27

-1шт.

|$11

SERVICE PARTS

-1шт.

4

6736-39-3400

BEARING, CONNECTING ROD - 0.25 MM O/S

-2шт.

4

6736-38-3400

BEARING, CONNECTING ROD - 0.50 MM O/S

-2шт.

4

6736-37-3400

BEARING, CONNECTING ROD - 0.75 MM O/S

-2шт.

4

6736-36-3400

BEARING, CONNECTING ROD - 1.00 MM O/S

-2шт.

|$16

6735-39-2210

KIT, ENGINE PISTON - 0.50 MM O/S

6шт.

5

NSS

PISTON, ENGINE

1шт.

6

6736-31-2510

RING, RETAINING

2шт.

7

6732-39-2300

SET, PISTON RING

1шт.

|$20

6735-38-2210

KIT, ENGINE PISTON - 1.00 MM O/S

6шт.

5

NSS

PISTON, ENGINE

1шт.

6

6736-31-2510

RING, RETAINING

2шт.

7

6732-38-2300

SET, PISTON RING

1шт.

|$28

-1шт.

|$25

R1 - REMANUFACTURED ASSEMBLY AVAILABLE: REFER TO REMANUFACTURED

-1шт.

|$26

ASSEMBLIES CATALOG.

-1шт.
