Запчасти Komatsu GD530A РАДИО УСТАНОВКА DIGITAL TUNER SUPERSTRUCTURE

|$0

1433 940 H91

RADIO INSTALLATION

1шт.

|$1

1431 316 H91

RADIO ASSEMBLY, AM/FM STEREO

1шт.

1

1434 714 H1

RADIO

1шт.

2

1434 921 H1

BUSHING, REAR

1шт.

3

1434 717 H1

HOUSING, RADIO/SPEAKER

1шт.

4

1434 718 H1

SPEAKER, 4 IN. DUAL CONE

2шт.

5

1434 719 H1

HARNESS, RADIO WIRING

1шт.

6

1434 715 H1

PLATE, ROOF MOUNTING

1шт.

7

1434 716 H1

BRACKET, REAR SUPPORT

1шт.

8

26 000 R1

SCREW, SHEET METAL

1шт.

9

1434 920 H1

ANTENNA

1шт.

10

187 540

GROMMET

1шт.

11

180 048

BOLT

2шт.

12

23 323 H

SPACER

2шт.

12

645 342 C1

SPACER - USE WITH SOUND INSULATION

2шт.

13

25 542 R1

WASHER, FLAT - USE WITH SOUND INSULATION

10шт.

N/I

1434 023 H1

SEALANT, ELECTRIC

1шт.

|$30

-1шт.

|$18

F1 - AM/FM CASSETTE STEREO SAME AS ABOVE EXCEPT AS FOLLOWS;

-1шт.

|$19

1433 942 H91

RADIO INSTALLATION

1шт.

|$20

1432 603 H91

RADIO, AM/FM CASSETTE STEREO

1шт.

|$21

1434 922 H1

RADIO/CASSETTE

1шт.

|$31

-1шт.

|$23

F2 - FOR CONVERTER MOUNTING SEE PG 08-047.

-1шт.

|$32

-1шт.

|$33

-1шт.

|$26

F3 - F1 AND F2 APPLY.

-1шт.

|$34

-1шт.

|$35

-1шт.

|$29

F4 - APPLY TO TERMINALS: FILL FEMALE CONNECTORS ONE-HALF FULL.

-1шт.

|$36

-1шт.
