Запчасти Komatsu GD530A КОНДИЦ. ВОЗДУХА ЛИНИИ заводской номер -97 SUPERSTRUCTURE

1

COMPRESSOR MOUNTING (SEE PG 13-150)

-29шт.

2

BELT, COMPRESSOR DRIVE (SEE PG 13-150)

-29шт.

|$2

1437 198 H91

KIT, CONDENSER HOSE AND COIL

1шт.

3

1431 743 H1

DRYER/RECEIVER

1шт.

4

1433 065 H1

HOSE - 13/32 X 5 FT

1шт.

5

1433 068 H1

HOSE - 5/16 X 6 FT

1шт.

6

1431 742 H1

COIL, CONDENSER

1шт.

7

1431 745 H1

BRACKET, DRYER/RECEIVER MOUNTING

1шт.

8

NSS

SWITCH, HIGH PRESSURE

1шт.

9

25 493 R1

BOLT

2шт.

|$10

25 533 R1

WASHER, FLAT

2шт.

|$11

25 520 R1

NUT, HEX

2шт.

|$12

161 496

SLEEVE, PROTECTIVE - 22 IN

1шт.

10

25 522 R1

NUT, HEX

1шт.

11

25 534 R1

WASHER, FLAT

1шт.

|$15

1432 856 H91

KIT, HOSE

1шт.

12

1433 067 H1

HOSE - 5/16 X 6 FT

1шт.

13

1433 066 H1

HOSE - 1/2 X 8 FT

1шт.

|$18

1431 737 H1

FITTING, EVAPORATOR DRAIN

2шт.

14

105 899

STUD, WELD

1шт.

15

651 569 C1

CLAMP

2шт.

16

25 553 R1

WASHER, FLAT

1шт.

17

17 044 R1

NUT, HEX

1шт.

|$23

1431 377 H1

SLEEVE, HOSE WRAP - 20 IN

1шт.

|$24

935 522 C1

STRAP, TIE

4шт.

18

BOX ASSEMBLY, AIR CONDITIONER/HEATER (SEE PG 13-140)

-1шт.

19

RADIATOR/OIL COOLER (SEE PG 06-010)

-29шт.

|$37

-1шт.

|$29

F1 - WRAP HOSES TOGETHER AT CONDENSER WITH SLEEVE P/N 161 496.

-1шт.

|$30

CUT SLEEVE TO LENGTH.

-1шт.

|$38

-1шт.

|$32

F2 - HIGH PRESSURE SWITCH IS NOW LOCATED IN EVAPORATOR CASE. USE

-1шт.

|$33

CAP P/N 9403 369 TO CONNECT THE WIRES TOGETHER IN HARNESS.

-1шт.

|$39

-1шт.

|$35

F3 - WRAP HOSES TOGETHER WITH BULK HOSE WRAP P/N 1431 377 H1. CUT

-1шт.

|$36

WRAP TO LENGTH.

-1шт.
