Запчасти Komatsu GD530A СИДЕНЬЕ КОРПУС SUPERSTRUCTURE

|$0

1432 859 H92

BOX ASSEMBLY, SEAT

1шт.

1

1434 975 H1

HOUSING, MAIN

1шт.

2

1435 642 H1

PLATE, SEAL

2шт.

3

1435 641 H1

FOAM, SEAL - 35 IN

1шт.

4

1434 948 H1

SEAL WELDMENT

2шт.

5

1434 988 H1

FOAM, HOUSING - BOTTOM

1шт.

6

1434 976 H1

COVER ASSEMBLY

1шт.

7

28 144 R1

BOLT

8шт.

8

120 394

WASHER, FLAT

8шт.

9

1434 947 H1

PLATE WELDMENT, CONTROL

1шт.

10

1434 987 H1

FOAM, SEAL - 15 IN

1шт.

11

1435 640 H1

PLATE, LOUVER COVER

2шт.

12

1434 987 H1

FOAM SEAL - 66 IN

1шт.

13

1435 668 H1

PLATE WELDMENT, LOUVER COVER

2шт.

14

1435 643 H1

PLUG - 3/4 IN

1шт.

15

418T 42A 240

PLUG - 7/8 IN

1шт.

|$18

-1шт.

|$17

F1 - CUT FOAM SEAL IN HALF TO USE AT BOTH LOCATIONS.

-1шт.

|$19

-1шт.
