Запчасти Komatsu GD530A КАПОТSUPERSTRUCTURE

|$0

1433 109 H91

HOOD SIDE INSTALLATION

1шт.

|$1

1433 107 H91

HOOD SIDE ASSEMBLY - L.H

1шт.

1

1433 102 H91

HOOD SIDE WELDMENT

1шт.

2

1246 804 H1

LOCK, ENGINE PANEL

1шт.

|$4

25 222 R1

BOLT

4шт.

|$5

1436 959 H1

SHIM

-2шт.

3

140 359

HANDLE, ENGINE PANEL

1шт.

|$7

593 762 R1

SCREW, SELF-TAPPING

3шт.

4

1432 711 H1

PROP, DOOR - GAS SPRING

2шт.

|$9

120 214

WASHER, LOCK

4шт.

|$10

25 520 R1

NUT, HEX

4шт.

5

25 519 R1

NUT

10шт.

6

1431 479 H1

STRIP, SEAL - 18.75 IN

2шт.

|$13

1433 105 H91

HOOD SIDE ASSEMBLY - R.H

1шт.

7

1433 100 H91

HOOD SIDE WELDMENT

1шт.

8

140 359

HANDLE, ENGINE PANEL

1шт.

|$16

593 762 R1

SCREW, SELF-TAPPING

3шт.

9

1246 804 H1

LOCK, ENGINE PANEL

1шт.

|$18

25 222 R1

BOLT

4шт.

|$19

1436 959 H1

SHIM

-2шт.

10

25 222 R1

BOLT

10шт.

11

25 532 R1

WASHER, FLAT

20шт.

12

SHELL WELDMENT, REAR (SEE PG 13-002)

-29шт.

13

HOOD TOP (SEE PG 13-006)

-29шт.

14

SHELL WELDMENT, FRONT (SEE PG 13-002)

-29шт.

15

1431 479 H1

STRIP, SEAL - 26.5 IN

2шт.

|$29

-1шт.

|$27

F1 - TO SECURE THE DOOR: USE PADLOCK P/N 650 382 C92 AND KEYS

-1шт.

|$28

P/N 1311 216 H1.

-1шт.
