Запчасти Komatsu GD530A ДВИГАТЕЛЬ ОБСТАНОВКА SOUND INSULATION SUPERSTRUCTURE

|$0

1434 538 H91

SOUND INSULATION, ENGINE COMPARTMENT

1шт.

1

1434 491 H1

INSULATION - HOOD TOP - L.H

1шт.

|$2

1434 492 H1

INSULATION - HOOD TOP - R.H

1шт.

2

1434 495 H1

INSULATION - TANK FRONT

1шт.

3

1434 496 H1

INSULATION - REAR SHELL - L.H

1шт.

|$5

1434 497 H1

INSULATION - REAR SHELL - R.H

1шт.

4

1434 490 H91

GRILL WELDMENT

1шт.

|$7

1434 504 H1

INSULATION - GRILL PLATE

1шт.

5

359 105 R1

SPACER

1шт.

|$9

24 841 R1

BOLT

1шт.

6

1434 499 H1

INSULATION - INNER REAR FRAME

1шт.

7

1434 551 H1

INSULATION - LOWER ENGINE PANEL

1шт.

8

1434 493 H1

INSULATION - HOODSIDE - L.H

1шт.

|$13

1434 494 H1

INSULATION - HOODSIDE - R.H

1шт.

|$14

444 028

BUSHING

1шт.

|$15

940 2825

ELBOW 45 DEGREES

1шт.

|$24

-1шт.

|$17

F1 - REMOVE GRILL WHEN ENGINE COMPARTMENT SOUND INSULATION IS

-1шт.

|$18

INSTALLED (SEE PG 13-003).

-1шт.

|$25

-1шт.

|$20

F2 - REMOVE EXISTING FITTING P/N 333 934 R1 AND REPLACE WITH THE

-1шт.

|$21

BUSHING AND ELBOW WHEN INSTALLING ENGINE SOUND COMPARTMENT

-1шт.

|$22

INSULATION.

-1шт.

|$23

-1шт.
