Запчасти Komatsu GD530A ОПЦ.AL РЫЧАГИ УПРАВЛ-Я ВСПОМОГ. ГИДРАВЛS

|$0

1250 391 H91

VALVE AND LEVER INSTALLATION - 10 VALVE

1шт.

|$1

1260 529 H91

VALVE AND LEVER INSTALLATION - 11 VALVE

1шт.

|$2

1260 530 H91

VALVE AND LEVER INSTALLATION - 12 VALVE

1шт.

1

1250 350 H3

KNOB, RIPPER

-2шт.

1

1250 351 H2

KNOB, DOZER/SNOW PLOW

-2шт.

1

1250 352 H2

KNOB, AUXILIARY

-2шт.

2

1232 274 H1

EPOXY, GENERAL PURPOSE

-2шт.

3

1252 574 H91

LEVER ASSEMBLY

-2шт.

|$8

120 437 H45

BEARING

2шт.

4

1253 026 H2

WASHER, BEARING

-2шт.

5

25 493 R1

BOLT

-2шт.

6

120 214

WASHER, LOCK

-2шт.

|$12

1244 338 H91

ROD ASSEMBLY, CONTROL

-2шт.

7

514 358 C1

END, ROD

1шт.

8

25 395 R1

NUT, JAM

2шт.

9

1244 348 H1

ROD, LINK

1шт.

10

1253 046 H1

BOOT

1шт.

11

1244 350 H91

ADAPTOR, SWIVEL

1шт.

12

LEVER, SCARIFIER (SEE PG 10-126)

-29шт.

13

1252 580 H91

LEVER ASSEMBLY

1шт.

|$20

120 437 H45

BEARING

2шт.

N/I

1253 034 H1

EXTENSION, UPPER SHAFT

-2шт.

|$22

24 621 R1

BOLT - 3/8-16 X 2 1/4 IN

-2шт.

|$23

24 844 R1

BOLT - 3/8-16 X 3 1/2 IN

-2шт.

|$32

-1шт.

|$25

F1 - KITS ALSO INCLUDE VALVE SECTION, TIE ROD, STRAIGHT CONNECTORS

-1шт.

|$26

AND O-RINGS: SEE PG 10-141, OR SEE PG 10-143, OR SEE PAGE 10-145.

-1шт.

|$33

-1шт.

|$28

F2 - FOR STANDARD CONTROL LEVERS SEE PG 05-007.

-1шт.

|$34

-1шт.

|$35

-1шт.

|$31

F3 - F1 AND F2 APPLY.

-1шт.

|$36

-1шт.
