Запчасти Komatsu GD530A ARTICULATION СОЕД-Е РАМА

1

24 876 R1

BOLT

8шт.

|$1

25 537 R1

WASHER, FLAT

8шт.

2

159 274

PLATE, RETAINING

4шт.

3

FRAME WELDMENT - FRONT (SEE PG 09-002)

-29шт.

3

FRAME WELDMENT - FRONT (SEE PG 09-004)

-29шт.

3

FRAME WELDMENT - FRONT (SEE PG 09-006)

-29шт.

3

FRAME WELDMENT - FRONT (SEE PG 09-008)

-29шт.

3

FRAME WELDMENT - FRONT (SEE PG 09-010)

-29шт.

3

FRAME WELDMENT - FRONT (SEE PG 09-012)

-29шт.

4

159 275

SPACER, BEARING

6шт.

5

159 288 H45

PIN

2шт.

6

25 285 R1

BOLT

6шт.

|$12

120 384

WASHER, LOCK

6шт.

|$13

25 526 R1

NUT, HEX

6шт.

7

140 020

CAP, BEARING

1шт.

8

109 461

FITTING, GREASE

2шт.

9

80 054

SEAL, OIL

2шт.

10

54 102

SHIM - 0.005 IN. (0.127 MM)

6шт.

|$18

54 103

SHIM - 0.007 IN. (0.178 MM)

6шт.

|$19

54 104

SHIM - 0.020 IN. (0.508 MM)

2шт.

11

140 000

BEARING

2шт.

12

159 271

CARTRIDGE, BEARING

2шт.

13

FRAME WELDMENT - REAR (SEE PG 09-002)

-29шт.

13

FRAME WELDMENT - REAR (SEE PG 09-004)

-29шт.

13

FRAME WELDMENT - REAR (SEE PG 09-006)

-29шт.

13

FRAME WELDMENT - REAR (SEE PG 09-008)

-29шт.

13

FRAME WELDMENT - REAR (SEE PG 09-010)

-29шт.

|$47

-1шт.

13

FRAME WELDMENT - REAR (SEE PG 09-012)

-29шт.

14

159 276

WASHER, THRUST

1шт.

15

140 021

CAP, BEARING

1шт.

16

19 974

SEAL, OIL

2шт.

17

102 095

SHIM - 0.005 IN. (0.127 MM)

3шт.

|$33

102 096

SHIM - 0.007 IN. (0.178 MM)

3шт.

|$34

102 091

SHIM - 0.020 IN. (0.508 MM)

1шт.

18

25 507 R1

BOLT

6шт.

|$36

120 384

WASHER, LOCK

6шт.

|$37

25 526 R1

NUT, HEX

6шт.

19

1431 489 H1

SHIM

2шт.

N/I

1436 643 H1

BAFFLE

2шт.

|$40

1436 642 H1

PLATE

4шт.

|$41

180 126

BOLT - BAFFLE TO REAR FRAME

8шт.

|$42

25 896 R1

WASHER, FLAT

16шт.

|$43

120 377

NUT, HEX

8шт.

|$44

140 483 H1

BOLT - BAFFLE TO FRONT FRAME

16шт.

|$45

24 841 R1

BOLT

8шт.

|$46

25 709 R1

WASHER

16шт.
