Запчасти Komatsu GD530A КОЛЕНВАЛ БЛОК ЦИЛИНДРОВ

|$0

6736-31-1100

CRANKSHAFT ASSEMBLY

1шт.

1

6732-31-1211

GEAR, CRANKSHAFT

1шт.

2

NSS

CRANKSHAFT

1шт.

3

6732-21-6150

PIN, DOWEL

1шт.

|$4

6735-21-8100

SET, MAIN BEARING - STANDARD

1шт.

4

NSS

BEARING, MAIN UPPER

6шт.

5

NSS

BEARING, THRUST

1шт.

6

NSS

BEARING, LOWER

7шт.

|$8

6736-29-8100

SET, MAIN BEARING - 0.25MM OVER

1шт.

4

NSS

BEARING, MAIN UPPER

6шт.

5

NSS

BEARING, THRUST

1шт.

6

NSS

BEARING, LOWER

7шт.

|$12

6736-28-8100

SET, MAIN BEARING - 0.50MM OVER

1шт.

4

NSS

BEARING, MAIN UPPER

6шт.

5

NSS

BEARING, THRUST

1шт.

6

NSS

BEARING, LOWER

7шт.

|$16

6736-27-8100

SET, MAIN BEARING - 0.75MM OVER

1шт.

4

NSS

BEARING, MAIN UPPER

6шт.

5

NSS

BEARING, THRUST

1шт.

6

NSS

BEARING, LOWER

7шт.

|$20

6736-26-8100

SET, MAIN BEARING - 1.00MM OVER

1шт.

4

NSS

BEARING, MAIN UPPER

6шт.

5

NSS

BEARING, THRUST

1шт.

6

NSS

BEARING, LOWER

7шт.

|$24

6736-29-8700

SET, CRANKSHAFT THRUST BRG - 0.50MM OVER

1шт.

5

NSS

BEARING, THRUST

1шт.

6

NSS

BEARING, LOWER

1шт.

|$27

6736-28-8700

SET, CRANKSHAFT THRUST BRG - 1.00MM OVER

1шт.

5

NSS

BEARING, THRUST

1шт.

6

NSS

BEARING, LOWER

1шт.

7

6736-39-1220

KIT, FRONT CRANK SLEEVE

1шт.

8

6736-39-1140

KIT, REAR CRANK SLEEVE (DRY FLYWHEEL)

1шт.

|$32

NSS

SLEEVE, WEAR DRY

1шт.

|$33

NSS

SEAL, OIL

a

1шт.

|$34

6736-39-1130

KIT, REAR CRANK SLEEVE (WET FLYWHEEL)

b

1шт.

|$35

NSS

SLEEVE, WEAR WET

1шт.

|$36

NSS

SEAL, OIL

1шт.

|$40

-1шт.

|$38

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$39

ASSEMBLIES CATALOG.

-1шт.
