Запчасти Komatsu GD530A БЛОК ЦИЛИНДРОВ БЛОК ЦИЛИНДРОВ

|$0

6736-21-1100

BLOCK ASSY, CYLINDER

1шт.

1

NSS

BLOCK, CYLINDER

1шт.

2

6732-21-1410

BUSHING

1шт.

3

6732-21-1610

BOLT (M14x2.00x119)

14шт.

4

6732-21-1210

CAP, MAIN BEARING (SEMI-FINISHED)

7шт.

5

6736-21-1810

PLUG, EXPANSION

6шт.

6

6732-21-1820

PLUG, EXPANSION (1 INCH)

4шт.

7

6732-21-1810

PLUG, EXPANSION (17.73 MM)

3шт.

8

6732-21-1910

DOWEL, RING (M18x10)

14шт.

|$9

6736-21-1090

KIT, BLOCK HARDWARE

1шт.

9

6732-21-6140

DOWEL, RING (M16x10)

2шт.

10

6732-21-1190

NOZZLE, PISTON COOLING

6шт.

11

6732-21-6130

PLUG, WELCH

1шт.

12

6732-21-6120

PIN DOWEL (M10x16)

2шт.

13

6732-11-1910

PLUG, PIPE (1/2 NPT)

1шт.

14

6732-11-1930

PLUG, PIPE (1/8 NPT)

2шт.

N/I

6732-21-1930

O-RING

1шт.

15

6735-21-5530

PLUG, EXPANSION (NOT USED ON TURBOCHARGED ENG)

1шт.

16

6732-21-1810

DOWEL, RING (M18x10)

2шт.

17

6732-21-5530

PLUG, EXPANSION

1шт.

18

6732-21-6160

PLUG, EXPANSION (NOT USED WITH SIDE OIL FILL)

1шт.

N/I

6732-21-1930

SEAL, O-RING

1шт.

|$31

-1шт.

|$23

SERVICE PARTS

-1шт.

2

6736-29-1410

BUSHING, OS - NO. 1 BORE

-2шт.

2

6736-29-1420

BUSHING, OS - NO. 2-5 BORE

-2шт.

4

6732-21-1210

CAP, MAIN BEARING (SEMI-FINISHED)

7шт.

19

6736-29-2110

SLEEVE, SALVAGE - STD BORE

-2шт.

|$32

-1шт.

|$29

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$30

ASSEMBLIES CATALOG.

-1шт.
