Запчасти Komatsu GD530A ГОЛОВКА ЦИЛИНДРОВ ГОЛОВКА ЦИЛИНДРОВ

|$0

6736-11-1110

HEAD, CYLINDER

1шт.

1

NSS

HEAD, CYLINDER

1шт.

2

6736-11-1150

PLUG, EXPANSION

5шт.

3

6732-11-1930

PLUG, PIPE - 1/8 NPT

2шт.

4

6732-11-1910

PLUG, PIPE - 1/2 NPT

5шт.

|$5

6736-41-4110

KIT, INTAKE VALVE

6шт.

5

6732-41-4520

COLLET, VALVE

12шт.

10

NSS

VALVE, INTAKE

6шт.

|$8

6736-41-4210

KIT, EXHAUST VALVE

6шт.

5

6732-41-4520

COLLET, VALVE

12шт.

11

NSS

VALVE, EXHAUST

6шт.

6

6732-41-4410

SPRING, VALVE

12шт.

7

6732-41-4510

RETAINER, VALVE SPRING

12шт.

8

6732-41-4530

SEAL, VALVE STEM

6шт.

9

6732-41-4540

SEAL, VALVE STEM

6шт.

12

6732-11-1920

PLUG, PIPE - 3/4 NPT

1шт.

13

6732-11-1610

BOLT (M12x1.75x70)

6шт.

14

6732-11-1620

BOLT (M12x1.75x120)

14шт.

|$$19

-1шт.

|$19

SERVICE PARTS

-1шт.

15

6736-19-1440

INSERT, VALVE - EXHAUST

-2шт.

16

6736-19-1430

INSERT, VALVE - INTAKE

-2шт.

17

6736-19-1310

GUIDE, VALVE STEM - INTAKE (THICK WALL)

-2шт.

18

6736-19-1410

GUIDE, VALVE STEM - EXHAUST (THICK WALL)

-2шт.

19

6736-18-1310

GUIDE, VALVE STEM - INT/EXH (THIN WALL)

-2шт.

20

6735-11-1811

GASKET, CYLINDER HEAD - STD

1шт.

|$26

6735-19-1820

GASKET, CYLINDER HEAD - .15MM OVERSIZE

-2шт.

|$27

6735-11-1840

GASKET, CYLINDER HEAD - .50MM OVERSIZE

-2шт.

|$$29

-1шт.

|$29

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$30

ASSEMBLIES CATALOG.

-1шт.
