Запчасти Komatsu GD530A КАПОТ SUPERSTRUCTURE

|$0

1243 065 H91

HOOD SIDE INSTALLATION

1шт.

|$1

1244 716 H91

HOOD SIDE ASSEMBLY - L.H

1шт.

1

1244 715 H91

HOOD SIDE WELDMENT

1шт.

2

140 363 H45

HINGE

1шт.

3

140 362

HINGE

1шт.

4

1246 804 H1

LOCK, ENGINE PANEL

1шт.

|$6

25 222 R1

BOLT

4шт.

|$7

120 380 R1

WASHER, LOCK

4шт.

5

140 359

HANDLE, ENGINE PANEL

1шт.

|$9

443 874

SCREW, MACHINE

3шт.

|$10

115 707

WASHER, LOCK

3шт.

6

140 360

PROP, DOOR - GAS SPRING

2шт.

|$12

120 214

WASHER, LOCK

4шт.

|$13

25 520 R1

NUT, HEX

4шт.

7

140 444

BRACKET, MOUNTING

2шт.

|$15

25 222 R1

BOLT

4шт.

|$16

120 380 R1

WASHER, LOCK

4шт.

8

140 441

PROP, DOOR

2шт.

|$18

25 222 R1

BOLT

8шт.

|$19

120 380 R1

WASHER, LOCK

8шт.

|$20

25 519 R1

NUT, HEX

4шт.

|$21

1246 806 H91

HOOD SIDE ASSEMBLY - R.H

1шт.

9

1246 805 H91

HOOD SIDE WELDMENT

1шт.

10

140 352

HINGE

1шт.

11

140 359

HANDLE, ENGINE PANEL

1шт.

|$25

443 874

SCREW, MACHINE

3шт.

|$26

115 707

WASHER, LOCK

3шт.

12

1246 804 H1

LOCK, ENGINE PANEL

1шт.

|$28

25 222 R1

BOLT

4шт.

|$29

120 380 R1

WASHER, LOCK

4шт.

13

25 222 R1

BOLT

10шт.

14

120 392

WASHER, FLAT

10шт.

15

25 551 R1

WASHER, FLAT

10шт.

16

SHELL WELDMENT, REAR (SEE PG 13-002)

-29шт.

17

HOOD TOP (SEE PG 13-008)

-29шт.

18

SHELL WELDMENT, FRONT (SEE PG 13-002)

-29шт.

19

1431 479 H1

STRIP, SEAL

6шт.
