Запчасти Komatsu GD530A TURBO LUBE POWER

|$0

1433 314 H91

LUBE INSTALLATION, TURBO

1шт.

|$1

1270 003 H91

KIT, TURBO LUBE

1шт.

1

1433 618 H1

TANK, OIL ACCUMULATOR

1шт.

|$3

1433 619 H1

ADAPTOR ASSEMBLY

1шт.

2

1433 614 H1

BRACKET, MOUNTING

1шт.

3

1433 612 H1

HOSE

1шт.

4

1433 611 H1

VALVE, ONE-WAY CHECK

1шт.

5

156 764 H1

CLAMP

1шт.

6

31 066 R1

BOLT

1шт.

7

78 825

SPACER

2шт.

8

1281 698 H1

SUPPORT

1шт.

9

25 222 R1

BOLT

4шт.

10

25 532 R1

WASHER, FLAT

4шт.

11

25 519 R1

NUT, HEX

4шт.

12

1285 161 H1

HOSE

1шт.

13

444 319

REDUCER

1шт.

14

9402 864

ELBOW, STREET - 90°

1шт.

15

86 191

BUSHING, REDUCER

1шт.

16

112 826

ADAPTOR, REDUCING

1шт.

17

1433 802 H1

PLATE, DECAL

1шт.

|$20

1433 778 H1

DECAL - TURBO LUBE

1шт.

N/I

1431 123 H1

PLUG - IN ENGINE BLOCK WHERE HOSE WAS REMOVED

1шт.

18

BOLT - USE EXISTING HARDWARE

2шт.

19

HOSE (SEE PG E1-010)

-29шт.

20

TURBOCHARGER (SEE PG E1-012)

-29шт.
