Запчасти Komatsu GD530A-1 SENDING БЛОКS ЭЛЕКТР.

1

114 951

SWITCH, BRAKE PRESSURE

1шт.

2

1430 227 H1

SWITCH, HIGH PRESSURE

1шт.

3

1282 169 H1

SWITCH, HYDRAULIC OIL TEMPERATURE

a

1шт.

|$3

158 982

SWITCH, HYDRAULIC OIL TEMPERATURE

b

1шт.

4

162 388

ELBOW, SPECIAL - 90°

1шт.

|$5

296 247 R1

O-RING

1шт.

5

1430 707 H1

SENDING UNIT, CONVERTER OIL TEMPERATURE

1шт.

6

1137 360 C2

SWITCH, ENGINE WATER TEMPERATURE

1шт.

7

1216 162 H1

SENDING UNIT, ENGINE WATER TEMPERATURE

1шт.

8

677 161 R92

SENDING UNIT, ENGINE OIL PRESSURE

1шт.

9

882 665 C1

SWITCH, ENGINE OIL PRESSURE

1шт.

10

1431 126 H1

SCREW, SELF-TAPPING

5шт.

11

55 845 A

SENDING UNIT, FUEL GAUGE

1шт.

12

29 362

GASKET

1шт.

13

163 109 H45

SWITCH, CLUTCH PRESSURE

1шт.

14

161 849

COUPLING, QUICK DISCONNECT

1шт.

15

162 144

CAP, DUST

1шт.

16

9409 935

TEE

-2шт.

17

443 977

ADAPTOR

-2шт.

|$21

-1шт.

|$20

F1 - 2 REQUIRED WITH AWD

-1шт.

|$22

-1шт.
