Запчасти Komatsu GD530A-1 AWD ЭЛЕКТРИКА ЭЛЕКТР.

1

PUMP & TRANSFER CASE (SEE PG 10-060)

-29шт.

2

1283 881 H93

HARNESS, REAR SENSOR

1шт.

3

WIRE - 1 AWD

-1шт.

4

WIRE - E AWD

-1шт.

5

WIRE - 1 AWD

-1шт.

6

WIRE - F AWD

-1шт.

7

299 406 C1

CLAMP

2шт.

8

1246 048 H1

SENSOR, MAGNETIC PICKUP - REAR

1шт.

9

1259 559 H2

CONTROLLER, ELECTRONIC

1шт.

10

RELAY, REVERSE (SEE PG 08-006)

-29шт.

11

704 523 C1

RELAY, AWD DISABLE

1шт.

12

1253 329 H1

HARNESS, FRONT SENSOR

1шт.

13

25 752 R1

BOLT

4шт.

|$13

25 542 R1

WASHER, LOCK

4шт.

14

VALVE, HIC (SEE PG 10-148)

-29шт.

15

386 170 C1

STRAP, TIE

-2шт.

16

1258 753 H1

SENSOR, MAGNETIC PICKUP - FRONT

1шт.

N/I

1430 440 H1

CABLE, JUMPER - FROM AWD FILTER TO HYDRAULIC FILTE

-2шт.
