Запчасти Komatsu GD530A-1 КОНЕЧНАЯ ПЕРЕДАЧА - БЕЗ PLANETARY ПРИВОД TRAIN

|$0

1431 782 H91

AXLE ASSEMBLY - NoSPIN DIFFERENTIAL

a

1шт.

|$1

1432 004 H91

AXLE ASSEMBLY - LOCK/UNLOCK DIFFERENTIAL

b

1шт.

1

25 772 R1

BOLT

8шт.

2

25 534 R1

WASHER, FLAT

8шт.

3

1281 013 H2

DISK, PARKING BRAKE

1шт.

4

30 023 R1

BOLT

5шт.

5

30 176 R1

WASHER, FLAT

5шт.

6

1430 033 H1

BRACKET, PARKING BRAKE

1шт.

8

159 906

GASKET, LIQUID - 300 ML CARTRIDGE

1шт.

9

CASE, DIFFERENTIAL (SEE PG 07-052)

-29шт.

10

1277 410 H1

RING, RETAINING

2шт.

11

1286 766 H91

BEARING, SPHERICAL ROLLER

2шт.

12

1286 767 H1

SEAL, OIL

2шт.

13

1277 393 H92

SLEEVE, TANDEM MOUNTING

2шт.

14

1285 337 H1

SEAL, GREASE

2шт.

|$15

1286 765 H91

BEARING ASSEMBLY

2шт.

15

1286 764 H91

BEARING, CONE

1шт.

16

1286 763 H1

BEARING, CUP

1шт.

17

1430 350 H92

HOUSING, FINAL DRIVE - L.H

1шт.

|$19

1430 351 H92

HOUSING, FINAL DRIVE - R.H

1шт.

18

30 076 R1

BOLT

24шт.

19

25 547 R1

WASHER, FLAT

24шт.

20

109 461

FITTING, LUBE

2шт.

|$23

625 365 C91

BEARING ASSEMBLY

2шт.

21

625 364 C1

BEARING, CUP

1шт.

22

625 363 C91

BEARING, CONE

1шт.

23

1283 309 H1

SHIM - 0.13 mm

-2шт.

|$27

1283 310 H1

SHIM - 0.18 mm

-2шт.

|$28

1283 311 H1

SHIM - 0.50 mm

-2шт.

24

1277 402 H3

RETAINER, BEARING

2шт.

25

22 422 R1

O-RING

2шт.

26

24 840 R1

BOLT

32шт.

|$32

1286 905 H91

SHAFT ASSEMBLY, AXLE

2шт.

27

1286 906 H1

SLEEVE, OUTPUT SHAFT

1шт.

28

1286 922 H1

SHAFT, AXLE

1шт.

29

1287 274 H1

GEAR, BRAKE PLATE

2шт.

30

1287 273 H1

RING, RETAINING

4шт.

31

621 247 C1

RING, RETAINING

2шт.

32

1287 272 H1

SPROCKET, OUTPUT SHAFT

4шт.

33

1286 819 H1

SPACER, OUTPUT SPROCKET

2шт.

34

19 875 R1

DOWEL, LOCATING

4шт.

35

CALIPER ASSEMBLY, PARKING BRAKE (SEE PG 04-014)

-29шт.

36

1430 239 H1

BOLT

2шт.

37

1430 240 H1

NUT

2шт.

38

1430 241 H1

PIN, SPLIT

2шт.
