Запчасти Komatsu GD530A-1 / INCH MOLDBOARD КРЕПЛЕНИЕED ОБОРУД-Е

|$0

1285 845 H91

MOLDBOARD ASSEMBLY - 3/4

1шт.

1

1285 850 H91

MOLDBOARD WELDMENT - 12'

1шт.

2

45 484 A

BOLT, PLOW - DOME HEAD

10шт.

3

25 537 R1

WASHER, LOCK

10шт.

4

9412 231

NUT, HEX

10шт.

5

140 199

BIT, REVERSIBLE END - FOR 5/8

2шт.

|$19

161 320

BIT, REVERSIBLE END - FOR 3/4

2шт.

6

45 045

EDGE, CUTTING - 5/8

-2шт.

|$8

86 333

EDGE, CUTTING - 5/8

-2шт.

|$9

1232 966 H1

EDGE, CUTTING - 5/8

-2шт.

|$10

161 318

EDGE, CUTTING - 3/4

-2шт.

|$11

92 441

EDGE, CUTTING - 3/4

-2шт.

7

45 484 A

BOLT, PLOW - DOME HEAD

17шт.

8

25 537 R1

WASHER, LOCK

17шт.

9

9412 231

NUT, HEX

17шт.

|$20

-1шт.

|$16

F1 - NOT INCLUDED IN MOLDBOARD ASSEMBLIES,

-1шт.

|$17

MUST BE ORDERED SEPARATELY

-1шт.
