Запчасти Komatsu GD530A-1 SHIFT КОНСОЛЬ POWER

1

160 541

SCREW, MACHINE

18шт.

2

120 392

WASHER, FLAT

18шт.

3

1285 655 H1

DECAL - THROTTLE

1шт.

4

1285 657 H3

COVER, SWITCH PANEL & GATE PLATE

1шт.

5

1285 656 H1

PLATE, GATE - THROTTLE CONTROL

1шт.

6

1285 464 H91

CONSOLE WELDMENT, SHIFT

1шт.

7

25 222 R1

BOLT

2шт.

8

25 542 R1

WASHER, FLAT

4шт.

9

1249 171 H2

COVER, CONSOLE - LOWER FRONT

1шт.

10

1283 515 H1

KNOB, THROTTLE LEVER

1шт.

11

25 222 R1

BOLT

2шт.

12

1237 011 H1

LEVER, THROTTLE CONTROL

1шт.

13

25 532 R1

WASHER, FLAT

6шт.

14

26 110 R1

NUT, LOCK

4шт.

15

25 672 R1

BOLT

2шт.

16

1237 012 H1

SPACER, THROTTLE CONTROL

2шт.

17

152 864

CONTROLLER, THROTTLE

1шт.

18

1287 526 H1

ARM, THROTTLE CONTROL

1шт.

19

25 752 R1

BOLT

2шт.

|$19

26 110 R1

NUT, LOCK

2шт.

20

SHIFTER, TRANSMISSION (SEE PG 12-028)

-29шт.
