Запчасти Komatsu GD355A-1 НАСОС ТРАНСМИССИИ(№8-) СИЛОВАЯ ПЕРЕДАЧА

1

23E-60-11201

PUMP ASS'Y

SN: 5084-UP

1шт.

|$$2

THE KAYABA KOGYO PART NUMBER IS THAT KB IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

2

KB20121-30705

FLANGE

SN: 5001-UP

1шт.

3

KB20121-30101

COVER

SN: 5001-UP

1шт.

4

0

GEAR,DRIVE (KIT A)

SN: 5001-UP

1шт.

5

0

GEAR,DRIVEN (KIT A)

SN: 5001-UP

1шт.

6

0

BUSHING (KIT A)

SN: 5001-UP

2шт.

7

0

BUSHING (KIT A)

SN: 5001-UP

2шт.

8

0

PACKING,RING (KIT B)

SN: 5001-UP

2шт.

9

0

PACKING,RING (KIT B)

SN: 5001-UP

2шт.

10

0

SEAL,BODY (KIT B)

SN: 5001-UP

2шт.

11

0

SEAL (KIT B)

SN: 5001-UP

2шт.

12

KB20121-31285

BOLT

SN: 5001-UP

4шт.

13

KB94101-10250

WASHER,SPRING

SN: 5001-UP

4шт.

14

0

SEAL,OIL (KIT B)

SN: 5001-UP

1шт.

15

0

RING,SNAP (KIT B)

SN: 5001-UP

1шт.

|$$17

SERVICE KIT

-1шт.

KIT A

23E-60-05130

SERVICE KIT,GEAR

SN: 5001-UP

1шт.

KIT B

23E-60-05140

SERVICE KIT,SEAL

SN: 5001-UP

1шт.
