Запчасти Komatsu PW98MR-6 ПРАВ. ПРИБОРНАЯ ПАНЕЛЬ КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

22U-43-R3140

UPPER BOX

2

37A-09-1W060

SCREW

3

01640-20610

WASHER

4

37A-09-1W043

SCREW

5

42N-06-13310

PLUG

6

21W-06-R1291

SWITCH, ROTARY BEAM

7

22L-09-R3Q20

BULB 30MA 24V

7

22L-09-R3Q40

BULB 1,2W 24V

8

21W-06-R1170

SWITCH, LIGHT

9

22L-09-R3Q20

BULB 30MA 24V

9

22L-09-R3Q40

BULB 1,2W 24V

10

21W-06-R1181

SWITCH, BUZZER

11

22L-09-R3Q20

BULB 30MA 24V

11

22L-09-R3Q40

BULB 1,2W 24V

12

22U-06-22470

KNOB

13

22U-43-23251

PROTECTION

14

22U-43-23290

CLIP

15

22U-43-R3111

PLATE

16

37A-09-1W042

SCREW

17

01601-20513

WASHER, SPRING

18

01640-20508

WASHER

19

22U-06-22480

SUPPORT

20

21W-43-R1390

BRACKET

21

21W-43-R1323

CONTROLLER, ENGINE SPEED

22

37A-09-1W059

SCREW

23

08034-20519

CLAMP

24

21W-06-R1540

SWITCH

25

37A-09-1W027

BOLT

26

01640-20408

WASHER

27

22U-43-23210

COVER

28

21W-06-R1420

SWITCH, HAZARD

29

22L-09-R3Q20

BULB 30MA 24V

29

22L-09-R3Q40

BULB 1,2W 24V

30

21W-06-R1191

SWITCH, PARKING BRAKE

31

22L-09-R3Q20

BULB 30MA 24V

31

22L-09-R3Q40

BULB 1,2W 24V

32

21W-06-R1220

SWITCH, LOCKING AXLE

33

22L-09-R3Q20

BULB 30MA 24V

33

22L-09-R3Q40

BULB 1,2W 24V

34

21W-06-R1230

SWITCH, ATTACHMENT

35

21W-06-R1210

SWITCH, BLADE FRONT OUTRIGGER
