Запчасти Komatsu PW98MR-6 СТАРТЕР (/) ДВИГАТЕЛЬ БЛОК

\0

6205-G0-RA10

MOTOR, ASSEMBLY

\0

600-863-3210

STARTING MOTOR, ASSEMBLY 3.0KW

1

KD0-24500-0141

CLUTCH ASSEMBLY, OVER RUNNING

2

KD0-24300-0030

FRONT BRACKET

3

KD1-21904-0230

PIN

4

KD0-24951-0070

PACKING

5

KD1-0505-00501

O-RING

6

KD0-24927-0030

STOPPER

7

KD0-24511-0040

PINION

8

KD1-23921-0150

WASHER

9

KD0-24610-0020

BRACKET, CENTRAL

10

KD0-24951-0100

GASKET

11

KD0-24200-0110

YOKE

12

KD0-24100-0080

ARMATURE

13

KD0-09271-3620

NAME PLATE

14

KD0-24921-0050

WASHER

15

KD0-24750-0100

BRUSH HOLDER

16

KD0-24921-0010

WASHER

17

KD0-24711-0130

BRACKET, REAR

18

KD1-09211-0520

O-RING

19

KD1-0400-20100

PIN

20

KD0-47100-4810

SWITCH, MAGNETIC

21

KD0-24951-0050

PACKING

22

KD0-47911-1300

SPRING

23

KD0-09001-5190

BOLT

24

KD0-09203-0010

BALL

25

KD0-09001-5370

BOLT

26

KD0-09252-0630

CAP

27

KD0-09001-5160

BOLT

28

KD0-09211-1440

O-RING

29

KD0-09011-2850

SCREW

30

KD0-47761-2741

COVER

31

KD0-09006-0660

NUT

32

KD0-09275-1430

PLATE, CAUTION
