Запчасти Komatsu PW98MR-6 ТОПЛ. НАСОС (/) ДВИГАТЕЛЬ БЛОК

\0

6205-G0-RA10

MOTOR, ASSEMBLY

\0

6205-71-1570

INJECTION PUMP, ASSEMBLY

\0

DK104641-7490

PUMP, ASSEMBLY

1

DK146018-9720

HOUSING

2

DK146304-0000

PIN

3

DK146305-0000

PIN

4

DK146600-0800

O-RING

5

DK146303-0000

O-RING

6

DK146300-0100

PISTON

7

DK146301-0000

PIN

8

DK146603-0700

SHIM, 0.600 MM

9

DK146302-1900

SPRING

10

DK146603-0700

SHIM, 0.600 MM

10

DK146603-0800

SHIM, 0.700 MM

10

DK146603-0900

SHIM, 0.900 MM

10

DK146603-1000

SHIM, 1.000 MM

10

DK146603-1100

SHIM, 1.200 MM

10

DK146603-3600

SHIM, 2.400 MM

11

DK146600-0800

O-RING

12

DK146310-0700

COVER

13

DK146620-5000

BOLT

14

DK146310-5100

COVER

15

DK146620-5000

BOLT

16

DK146891-1220

LEVER

17

DK146568-0000

BOLT

18

DK026508-1140

GASKET

19

DK146569-0300

NUT

20

DK146570-0520

SHAFT

21

DK146600-0400

O-RING

22

DK146571-0000

SHIM, 1.050 MM

22

DK146571-0100

SHIM, 1.250 MM

22

DK146571-0200

SHIM, 1.450 MM

22

DK146571-0300

SHIM, 1.650 MM

22

DK146571-0400

SHIM, 1.850 MM

22

DK146571-0500

SHIM, 1.150 MM

22

DK146571-0600

SHIM, 1.350 MM

22

DK146571-0700

SHIM, 1.550 MM

22

DK146571-0800

SHIM, 1.750 MM

23

DK146602-0600

WASHER

24

DK146572-0020

GEAR, RING

25

DK146602-2600

WASHER

26

DK146976-2600

BUSHING

27

DK146576-0400

PLUG

28

DK146877-0820

PLUG

28

DK146877-0920

PLUG

28

DK146877-1020

PLUG

28

DK146877-1120

PLUG

28

DK146877-1220

PLUG

28

DK146877-1320

PLUG

28

DK146877-1420

PLUG

28

DK146877-1520

PLUG

28

DK146877-1620

PLUG

28

DK146877-1720

PLUG

28

DK146877-1820

PLUG

28

DK146877-1920

PLUG

28

DK146877-2020

PLUG

28

DK146877-2120

PLUG

28

DK146877-2220

PLUG

28

DK146877-2320

PLUG

28

DK146877-2420

PLUG

28

DK146877-2520

PLUG

28

DK146877-2620

PLUG

28

DK146877-2720

PLUG

28

DK146877-2820

PLUG

28

DK146877-2920

PLUG

28

DK146877-3020

PLUG

28

DK146877-3120

PLUG

28

DK146877-3220

PLUG

28

DK146877-3320

PLUG

28

DK146877-3420

PLUG

28

DK146877-3520

PLUG

28

DK146877-3620

PLUG

28

DK146877-3720

PLUG

28

DK146877-3820

PLUG

28

DK146877-3920

PLUG

28

DK146877-4020

PLUG

28

DK146877-4120

PLUG

28

DK146877-4220

PLUG

29

DK146574-0320

COUNTER WEIGHT

30

DK146879-3920

PIN

31

DK146580-2800

SPRING

32

DK146600-0600

O-RING

33

DK146600-0700

O-RING

34

DK146110-0220

VALVE

35

DK146114-0000

RING, SNAP

36

DK139512-0500

GASKET

37

DK146125-0020

BOLT

38

DK146614-0200

SPACER

39

DK146601-1100

SEAL, OIL

40

DK146984-7100

PLATE

41

DK146598-8120

PLUG

41

DK145598-8320

PLUG

42

DK146600-1120

KIT, REPAIR (NOT SHOWN)
