Запчасти Komatsu PW98MR-6 МЕХАНИЗМ ПОВОРОТА, ВНУТР. ЧАСТИ (/) РАБОЧЕЕ ОБОРУДОВАНИЕ ГИДРАВЛИКА

\0

708-7S-00260

SWING MOTOR, ASSEMBLY

\0

708-7S-01212

MOTOR, ASSEMBLY

1

708-7S-21111

PLATE

2

708-7S-21511

CASE, MOTOR

3

706-73-71450

PLUG

4

07002-11423

O-RING

5

709-25-11650

VALVE

6

700-80-63230

SPRING

7

708-7S-21610

PLUG

8

07002-12434

O-RING

\8

706-73-72710

VALVE, ASSEMBLY

9

706-73-72720

VALVE

10

706-73-72730

POPPET

11

706-73-72740

PLUG

12

706-73-72440

SPRING

13

708-7S-21620

PLUG

14

07002-12434

O-RING

15

07000-12145

O-RING

16

720-68-19610

PIN

17

01252-61245

BOLT, HEXAGON SOCKET HEAD

18

708-7S-22110

SHAFT

19

708-7S-22140

BEARING

20

708-7S-22150

BEARING

21

708-7T-12230

SEAL

22

708-7S-22310

COVER

23

07000-12055

O-RING

24

04065-06020

RING, SNAP

25

708-7S-23110

CYLINDER BLOCK

26

708-7S-23210

PLATE, VALVE

27

720-68-19610

PIN

28

708-2L-23360

PIN

29

708-7S-13530

SPACER

30

708-7S-23510

SPRING

31

04065-03212

RING, SNAP

32

708-1S-13350

SLEEVE

33

708-1S-13340

RETAINER PLATE

34

708-7S-23310

PISTON, ASSEMBLY

35

708-7S-23410

SWASH PLATE

36

708-7S-25130

PLATE

37

708-7S-25120

DISK

38

708-7S-25140

PISTON, BRAKE

39

07000-12130

O-RING

40

07000-12120

O-RING

41

708-7S-25150

O-RING
