Запчасти Komatsu PW98MR-6 ПРАВ. COVER ЧАСТИ КОРПУСА И КАБИНА

\0

21W-46-48180

COVER R.H., ASSEMBLY

1

01010-80620

BOLT

2

01643-30623

WASHER

3

01010-81020

BOLT

4

01643-31032

WASHER

5

01010-81225

BOLT

6

01643-31232

WASHER

7

01023-10410

SCREW

8

01023-10512

SCREW

9

01643-30823

WASHER

10

04052-10833

PIN, SNAP

11

08037-02512

GROMMET

12

20B-54-12210

CLAMP

13

20R-54-11460

SPRING

14

21W-46-48112

COVER R.H.

15

21W-46-48121

COVER

16

21W-46-48151

HINGE

17

21W-46-48170

SHEET

18

21W-46-41641

SEAL

19

21W-46-41660

GROMMET

20

21W-46-41670

BRACKET

21

21W-46-41711

LOCK, ASSEMBLY

22

21W-46-48130

SEAL

23

21W-46-41750

LOCK, ASSEMBLY

24

21W-46-41780

SHEET

25

21W-54-41361

ROD

26

566-54-11340

GROMMET

27

01010-81230

BOLT

28

130-43-64260

COLLER

29

01010-81270

BOLT

30

01643-11232

WASHER

31

113-03-21160

SEAT

32

515-02-11330

BUSHING

33

566-35-42430

WASHER

34

02891-02015

O-RING

35

01010-81240

BOLT

36

01643-11232

WASHER

37

419-54-11270

SPACER

38

566-35-42430

WASHER

39

01010-81225

BOLT

40

01643-11232

WASHER

41

21W-09-R7150

SEAL
