Запчасти Komatsu PW98MR-6 ЗАДН. МОСТ (/8) НИЖН.CARRIAGE

Схема запчастей Komatsu PW98MR-6 - ЗАДН. МОСТ (/8) НИЖН.CARRIAGE
5
15
6
10
9
11
7
8
4
12
14
13
3
24
2
25
1
23
20
22
27
19
21
17
16
18
11
10
29
31
30
32
33
26
28
25
42
34
35
39
37
38
40
36
41

Артикул

Название

Примечание

Количество

\0

21W-22-R1010

REAR AXLE, ASSEMBLY

1

DG2120670222

HOUSING, ASSEMBLY

2

HOUSING

3

226-22-11640

BUSHING

4

DG2120670322

HOUSING, ASSEMBLY

5

HOUSING

6

226-22-11640

BUSHING

7

226-22-11670

PIN, ASSEMBLY

8

PIN

9

22E-23-11550

GREASE NIPPLE

10

22E-23-11990

PLUG

11

226-22-11350

SCREW

12

226-22-11930

SHIM, 0.150 MM

12

226-22-11940

SHIM, 0.200 MM

12

226-22-11950

SHIM, 0.500 MM

13

226-22-11651

BUSHING

13

DG2120600603

BUSHING

14

226-22-11690

SEAL

15

226-22-11660

COVER

16

226-22-11680

PIN, ASSEMBLY

17

PIN

18

22E-23-11550

GREASE NIPPLE

19

226-22-11690

SEAL

20

226-22-11710

JOINT

21

DG2130671101

BOLT, ASSEMBLY

22

226-22-11882

BOLT

23

226-22-11890

NUT

24

226-22-11751

SEAL

25

226-22-11760

BEARING

26

21D-23-12641

WHEEL, HUB

27

21D-23-11820

STUD

28

21D-23-11110

O-RING

29

DG2120670707

CROWN WHEEL, ASSEMBLY

30

226-22-11780

CROWN WHEEL

31

226-22-11870

RING

32

226-22-11791

WHEEL, CARRIER

33

226-22-11920

PLATE

34

226-22-11850

STUD

34

DG1120602502

STUD

35

226-22-11860

NUT

35

DG006224380

NUT

36

DG2120671020

PLANETARY CARRIER, ASSEMBLY

37

226-22-11820

BEARING, NEEDLE

38

226-22-11830

BEARING

39

226-22-11810

RING, SNAP

40

21D-23-12652

PLANETARY CARRIER

41

21D-23-12111

SCREW

42

21D-23-11971

PLUG

Выбрано товаров: 48
