Запчасти Komatsu PW98MR-6 ЗАДН. МОСТ (/8) НИЖН.CARRIAGE

\0

21W-22-R1010

REAR AXLE, ASSEMBLY

\0

DG3571440026

TRANSMISSION , ASSEMBLY

1

22E-22-11211

COVER

2

22E-22-11270

BOLT

3

226-22-11220

SHAFT

4

DG005014000

BEARING

5

22E-22-11250

PIN

6

22E-22-11261

HOUSING

7

22E-22-11310

SPACER

8

226-22-11230

GEAR

9

22E-22-11320

BOLT

10

DG011053997

WASHER

11

DG3571413302

PLATE

12

21D-14-11230

BEARING

13

226-22-11110

SHAFT

14

22E-22-11360

SLEEVE

14

DG3531410103

SLEEVE

15

22E-22-11370

GEAR

16

DG3571413202

PLATE

17

22E-22-11390

SPACER

18

226-22-11140

CYLINDER

19

226-22-11170

PISTON

20

22E-22-11491

PLATE

21

21D-14-11180

SLIDE BLOCK

22

22E-22-11520

FORK

23

22E-22-11530

SHAFT

24

22E-22-11630

SEAL

25

22E-22-12410

O-RING

26

226-22-11180

O-RING

27

226-22-11160

O-RING

28

226-22-11150

ROD

29

22E-22-11540

O-RING

30

22E-22-12420

PIN, SPRING

31

22E-22-12390

BOLT

32

21D-23-11290

SPRING WASHER

33

226-22-11130

O-RING

34

226-22-11120

SCREW
