Запчасти Komatsu PW95R-2 БОКОВ. КРЫШКА ДВИГ. ЧАСТИ КОРПУСА И КАБИНА

1

21D-54-11990

HOOD, L.H.

2

01010-51025

BOLT

3

01643-31032

WASHER

4

21D-54-11590

GASKET

5

21D-54-11113

HOOD, R.H.

6

21D-54-11970

GASKET

7

21D-54-11122

FLANGE

8

01010-50820

BOLT

9

01643-30823

SPRING WASHER

10

226-54-11241

GASKET

11

21D-54-11870

GASKET

12

226-54-11450

HINGE

13

21D-54-11192

DAMPER

14

21D-09-85140

PIN, COTTER

15

226-54-11312

HOOD

15

226-54-11313

HOOD

16

226-54-11440

GASKET

17

20M-54-72250

BOOT

18

22E-54-11650

PUSH-BUTTON, ASSY.

19

226-54-11140

SPACER

20

21D-09-14120

SCREW

21

01580-10605

NUT

22

226-54-11130

LOCK, ASSY.

23

21D-09-15150

SCREW

24

01580-10806

NUT

25

22E-54-11360

SUPPORT

26

21D-54-11260

PIN

27

01643-31232

WASHER

28

22E-54-11270

NUT

29

226-54-11170

HANDLE

30

22E-54-11370

GASKET

31

01010-51030

BOLT

32

21D-54-11660

SHIM

33

21D-09-81700

COLLAR

34

01010-51016

BOLT

35

01643-31032

WASHER

36

22E-54-11640

SHIM

37

21D-54-15240

COVER

38

01643-30823

SPRING WASHER

39

01010-50820

BOLT

40

22E-54-11430

SUPPORT
