Запчасти Komatsu PW95R-2 ПЕРЕДНИЙ МОСТ (/) ХОДОВАЯ

\0

21D-23-10021

FRONT AXLE, ASSY.

1

226-22-11721

HOUSING

1

226-22-11722

HOUSING

2

226-22-11741

HOUSING

2

226-22-11742

HOUSING

3

226-22-11640

BUSHING

4

226-22-11670

PIN, ASSY.

5

PIN

6

22E-23-11550

FITTING

7

22E-23-11990

PLUG

8

226-22-11350

BOLT

9

226-22-11930

SHIM, 0.150 mm

9

226-22-11940

SHIM, 0.200 mm

9

226-22-11950

SHIM, 0.500 mm

10

226-22-11650

BUSHING

10

226-22-11651

BUSHING

11

226-22-11690

SEAL

12

226-22-11660

COVER

13

226-22-11680

PIN, ASSY.

14

PIN

15

22E-23-11550

FITTING

16

226-22-11690

SEAL

17

226-22-11710

ARTICULATION

18

226-22-11881

CHECK BOLT

19

226-22-11890

NUT

20

226-22-11750

SEAL

21

226-22-11760

BEARING

22

21D-23-12641

WHEEL HUB

23

21D-23-11820

STEERING COLUMN

24

21D-23-11110

O-RING

25

22E-23-12510

PLANET GEAR CARRIER, ASSY

26

226-22-11780

GEAR, RING

27

226-22-11870

RING

28

226-22-11790

SUPPORT

29

226-22-11820

PLANET WHEEL

30

226-22-11830

BEARING

31

226-22-11810

RING

32

21D-23-12651

PLANET GEAR CARRIER

32

21D-23-12652

PLANET GEAR CARRIER

33

226-22-11920

PLATE

34

226-22-11850

STUD

35

226-22-11860

NUT

36

21D-23-12111

SCREW

37

21D-23-11970

PLUG

38

21D-23-11960

WASHER

39

21D-23-11850

NUT
