Запчасти Komatsu PW95R-2 ЭЛЕКТРИКА (ЛИНИЯ ДВИГАТЕЛЯ) КОМПОНЕНТЫ ДВИГАТЕЛЯ И ЭЛЕКТРИКА

1

226-06-11400

WIRING HARNESS

2

226-06-11320

COVER

3

226-06-11330

KNOB

4

226-06-11340

PLATE

5

01010-50630

BOLT

6

21D-09-73490

SPRING WASHER

7

01580-10605

NUT

8

22E-06-11640

RELAY HOLDER

9

226-06-11350

RELAY

10

22E-06-11570

FUSE BOX

11

22E-06-11580

COVER

12

22E-06-11590

FUSE 30A

12

22E-06-11620

FUSE 50A

12

226-06-11360

FUSE 70A

12

226-06-11370

FUSE 80A

13

21D-09-73480

SPRING WASHER

14

21D-09-21420

NUT

15

YM119632-77920

TIMER 1''

16

YM128300-77920

TIMER 15''

17

YM129100-77910

RELAY

18

226-06-11380

EC. POWER BOX

19

226-06-11170

SUPPORT

20

01010-50820

BOLT

21

01643-30823

SPRING WASHER

22

21D-09-81710

CLAMP

23

21D-06-11980

CABLE

24

01010-51020

BOLT

25

01643-31032

SPRING WASHER

26

226-06-11180

SUPPORT

27

01010-51020

BOLT

28

01643-31032

SPRING WASHER

29

226-06-11190

WIRING HARNESS, REAR

30

21D-06-11370

REAR LIGHT, ASSY.

31

01580-10605

NUT

32

21D-09-73840

WASHER

33

21D-06-11570

BULB 21W

34

21D-06-11580

BULB 7W

35

21D-06-11380

REFLEX REFLECTOR

36

22E-06-11860

TEMPERATURE TRANSMITTER

37

21D-54-11850

SUPPORT

38

01435-00820

SCREW
