Запчасти Komatsu PW95R-2 ГИДРОЛИНИЯ (PPC ТРУБЫ) (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

21D-09-51190

UNION

2

21D-09-69910

O-RING

3

21D-09-55620

ELBOW

4

22E-09-12160

HOSE

5

21D-09-51630

ELBOW

6

21D-09-69910

O-RING

7

22E-09-12570

HOSE

8

21D-09-97370

HOSE

9

21D-09-55670

ELBOW

10

21D-09-52520

TEE

11

21D-09-51190

UNION

12

21D-09-69910

O-RING

13

22E-09-14120

HOSE

14

21D-09-51180

UNION

15

21D-60-17120

VALVE

16

21D-09-53530

UNION

17

21D-09-58350

TEE

18

21D-09-69910

O-RING

19

21D-09-66810

UNION

20

21D-60-17310

ACCUMULATOR

21

226-60-18210

SUPPORT

22

01010-51020

BOLT

23

01643-31032

SPRING WASHER

24

22E-62-11430

REDUCTION

25

226-60-18701

SOLENOID VALVE, ASSY.

26

HOLDER, VALVE W/CASE

27

226-60-18120

COIL, ASSY.

28

226-60-18130

SCREW

29

21D-60-18531

VALVE

30

226-60-18111

COIL

31

01010-50816

BOLT

32

01643-30823

SPRING WASHER

33

21D-09-52520

TEE

34

21D-09-97310

HOSE

35

21D-09-51190

UNION

36

21D-09-69910

O-RING

37

21D-09-54720

PLUG

38

21D-09-73160

GASKET
