Запчасти Komatsu PW95R-2 БОКОВ. КРЫШКА ДВИГ. ЧАСТИ КОРПУСА И КАБИНА

1

21D-54-11111

HOOD

2

01010-51025

BOLT

3

01643-31032

SPRING WASHER

4

21D-54-11590

GASKET

5

22E-54-11330

GASKET

6

226-54-11220

GASKET

7

21D-54-11121

COVER

8

01010-50820

BOLT

9

01643-30823

SPRING WASHER

10

21D-54-11810

GASKET

11

21D-54-11820

GASKET

12

21D-54-11560

HINGE

13

21D-54-11190

DAMPER

14

21D-09-85140

PIN, COTTER

15

226-54-11311

HOOD

16

226-54-11320

GASKET

17

20M-54-72250

CATCH

18

226-54-11150

PUSH-BUTTON, ASSY.

18

22E-54-11650

PUSH-BUTTON, ASSY.

19

226-54-11140

SPACER

20

01252-40640

SCREW

21

01580-10605

NUT

22

226-54-11130

LOCK, ASSY.

23

21D-09-15150

SCREW

24

01580-10806

NUT

25

226-54-11160

SUPPORT

26

21D-54-11260

PIN

27

01643-31232

WASHER

28

22E-54-11270

NUT

29

226-54-11170

HANDLE

30

21D-54-11830

GASKET

31

01010-51030

BOLT

32

21D-54-11660

SHIM

33

21D-09-81700

COLLAR

34

01010-51016

BOLT

35

01643-31032

SPRING WASHER

36

22E-54-11640

SHIM
