Запчасти Komatsu PW95R-2 ПЕРЕДНИЙ МОСТ (/) ХОДОВАЯ

\0

21D-23-10020

FRONT AXLE, ASSY.

1

226-22-11720

HOUSING

1

226-22-11721

HOUSING

2

226-22-11740

HOUSING

2

226-22-11741

HOUSING

3

226-22-11670

PIN, ASSY.

4

PIN

4

226-22-11881

BOLT

5

22E-23-11550

FITTING

6

22E-23-11990

PLUG

7

226-22-11350

BOLT

8

226-22-11930

SHIM, 0.150 mm

8

226-22-11940

SHIM, 0.200 mm

8

226-22-11950

SHIM, 0.500 mm

9

226-22-11650

RING

10

226-22-11660

COVER

11

226-22-11680

PIN, ASSY.

12

PIN

13

22E-23-11550

FITTING

14

226-22-11690

SNAP RING

15

226-22-11710

ARTICULATION

16

226-22-11910

SPACER

17

226-22-11880

CHECK BOLT

18

226-22-11890

NUT

19

226-22-11750

SNAP RING

20

226-22-11760

BEARING

21

21D-23-12640

WHEEL HUB

21

21D-23-12641

WHEEL HUB

22

21D-23-11820

STEERING COLUMN

23

21D-23-11110

O-RING

24

226-22-11780

GEAR, RING

25

226-22-11870

RING

26

226-22-11790

SUPPORT

27

226-22-11920

PLATE

28

226-22-11850

STUD

29

226-22-11860

NUT

30

226-22-11820

PLANET WHEEL

31

226-22-11830

BEARING

32

226-22-11810

RING

33

21D-23-12650

PLANET GEAR CARRIER

33

21D-23-12651

PLANET GEAR CARRIER

34

21D-23-12110

SCREW

34

21D-23-12111

SCREW

35

21D-23-11970

PLUG

36

21D-23-11960

WASHER

37

21D-23-11850

NUT
