Запчасти Komatsu PW95R-2 СЕРВОУПРАВЛ. УСТР-ВО ПОДАЧИ УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

702-21-09192

SERVOCONTROL FEED UNIT, ASSY.

1

SLEEVE

2

702-21-55310

VALVE

3

702-21-55460

SPRING

4

702-21-55420

O-RING

5

702-21-55520

O-RING

6

702-21-55440

O-RING

7

702-21-53120

FILTER

8

07000-11009

O-RING

9

702-21-55490

COVER

10

01252-60516

SCREW

11

702-21-55530

O-RING

12

COVER

13

702-21-55511

SPOOL

14

702-21-55640

SPRING

15

702-21-55100

RELIEF VALVE

16

SLEEVE

17

SLEEVE

18

702-21-55760

FILTER

19

VALVE

20

SPRING

21

SCREW

22

01582-11008

NUT

23

723-11-19660

O-RING

24

702-16-53920

O-RING

25

07002-11023

O-RING

26

07002-11623

O-RING

27

702-21-55710

SEAT

28

702-21-55720

SPRING

29

04260-00793

BALL

30

07000-11009

O-RING

31

706-86-51180

PLUG

32

702-21-55670

ORIFICE

33

702-21-55470

ORIFICE

34

01252-61040

SCREW

35

01643-51032

WASHER

36

702-21-55620

PLUG

37

07002-11423

O-RING

38

702-21-55390

FLANGE

39

01252-60525

SCREW

40

07000-13032

O-RING
