Запчасти Komatsu PW95-1 ЗАДН. МОСТ (/) ХОДОВАЯ

\0

21D-22-11320

REAR AXLE, ASSY.

1

01010-50610

BOLT

2

21D-23-11260

PLATE

3

21D-23-11270

RING, NUT

4

21D-23-11280

BEARING

5

01010-51230

BOLT

6

21D-23-11370

COVER

7

21D-23-11310

WASHER

8

21D-23-11320

CROWN WHEEL

8

21D-23-11321

CROWN WHEEL

9

21D-23-11360

PLANET WHEEL

9

21D-23-11361

PLANET WHEEL

10

21D-23-11330

SHIM

11

21D-23-11380

PIN

12

21D-23-11350

PEG

13

21D-23-11340

PIN

14

21D-23-11640

CORSS JOURNAL

15

21D-23-11300

BEVEL GEAR PAIR, ASSY.

15

21D-23-11301

BEVEL GEAR PAIR, ASSY.

16

21D-23-11390

PLANETARY CARRIER

17

21D-23-11290

SPRING WASHER

18

21D-23-12570

BOLT

19

21D-23-11470

BEARING

20

21D-23-11530

SHIM, 0.200 mm

20

21D-23-11540

SHIM, 0.250 mm

20

21D-23-11550

SHIM, 0.300 mm

20

21D-23-11560

SHIM, 0.350 mm

21

21D-23-11480

SPACER, 42.020 mm

21

21D-23-11490

SPACER 42.040 mm

21

21D-23-11510

SPACER, 42.060 mm

21

21D-23-11520

SPACER, 42.080 mm

22

21D-23-11570

SHIM, 0.350 mm

22

21D-23-11580

SHIM, 0.400 mm

22

21D-23-11590

SHIM, 0.450 mm

22

21D-23-11620

SHIM, 0.500 mm

22

21D-23-11610

SHIM, 0.550 mm

22

21D-23-11630

SHIM, 0.600 mm

23

21D-23-11460

RING, NUT

24

21D-23-11450

GASKET SEAL

25

21D-23-11440

PROTECTION

26

21D-23-11430

FLANGE

27

21D-23-11420

O-RING

28

21D-23-11410

NUT
