Запчасти Komatsu PW95-1 ПЕРЕДНИЙ МОСТ (/) ХОДОВАЯ

\0

21D-23-12580

FRONT AXLE, ASSY.

1

21D-23-11670

PIN, ASSY.

1

21D-23-11671

PIN, ASSY.

2

PIN

3

21D-09-89140

FITTING

4

21D-23-11740

BEARING

5

01010-51235

BOLT

5

01010-51235

BOLT

6

21D-23-11680

SHIM, 0.100 mm

6

21D-23-11690

SHIM, 0.250 mm

6

21D-23-11710

SHIM, 0.500 mm

7

21D-23-11720

SEAL DUST

8

21D-23-11730

O-RING

9

21D-23-12330

CHECK BOLT

10

21D-09-21760

NUT

11

21D-23-11750

JOINT

11

21D-23-11751

JOINT

11

21D-23-11752

JOINT

12

21D-23-11760

KNUCKLE

12

21D-23-11761

JOINT

12

21D-23-11762

JOINT

13

21D-23-11770

O-RING

14

21D-23-11780

SNAP RING

14

21D-23-11781

SNAP RING

15

21D-23-11790

SPACER

16

21D-23-11810

BEARING

17

21D-23-11820

STEERING COLUMN

18

21D-23-11830

HUB

19

21D-23-11840

O-RING

20

21D-23-11850

NUT

21

21D-23-12170

SHIM, 0.150 mm

21

21D-23-12180

SHIM, 0.200 mm

21

21D-23-12210

SHIM, 0.250 mm

21

21D-23-12220

SHIM, 0.300 mm

21

21D-23-12190

SHIM, 0.500 mm

22

21D-23-11860

RING

23

21D-23-12160

SHIM

24

21D-23-11870

SUPPORT

25

21D-23-11880

PIN

26

21D-23-11890

PROTECTION

27

21D-23-12150

BOLT

28

21D-23-11910

PINION

28

21D-23-11911

PINION GEAR

29

21D-23-11920

GEAR, RING

30

21D-23-11930

RING, SNAP

31

21D-23-11940

SHIM

32

21D-23-11950

CASE

33

21D-23-12140

SHIM

34

21D-23-12120

BEARING

35

21D-23-12130

PLANET WHEEL

36

21D-23-12370

SPACER

37

21D-23-12110

SCREW

38

21D-23-11990

PIN

39

21D-23-11980

O-RING

40

21D-23-11970

PLUG

41

21D-23-11960

WASHER

42

22E-23-11570

WASHER

42

22E-23-11570

WASHER
