Запчасти Komatsu PW95-1 ТРАНСМИССИЯ (/) ХОДОВАЯ
№
Артикул
Название
Примечание
Количество
\0
21D-14-10020
TRANSMISSION, ASSY.
1
01010-51025
BOLT
2
21D-14-11640
COVER
3
21D-14-11650
O-RING
4
21D-14-11810
SLEEVE
5
21D-14-11660
SELECTOR SHAFT
6
21D-14-11820
RING
7
21D-09-69370
O-RING
8
21D-09-21450
NUT
9
21D-09-74480
SPRING WASHER
10
21D-14-11670
STUD
11
21D-14-11690
SCREW
12
21D-14-11710
SPRING
13
21D-14-11680
BALL
14
21D-23-11120
BREATHER
15
21D-14-11720
PLUG
16
01010-51065
BOLT
17
21D-14-11790
HOUSING
18
21D-09-69310
O-RING
19
21D-14-11730
PISTON
20
21D-14-11740
SHIM
21
21D-09-69320
O-RING
22
21D-14-11750
PISTON
23
21D-14-11830
SHIM, 2.800 mm
23
21D-14-11840
SHIM, 3.100 mm
23
21D-14-11850
SHIM, 3.400 mm
24
21D-09-69330
O-RING
25
21D-14-11760
RING, SNAP
26
21D-14-11770
PISTON
27
21D-09-69130
O-RING
28
21D-09-69340
O-RING
29
21D-09-69350
O-RING
30
21D-14-11780
SLEEVE
31
21D-09-69360
O-RING
32
21D-14-11860
RING, SNAP
33
21D-14-11870
RING, SNAP
34
21D-14-11880
SHIM, 2.000 mm
35
21D-14-11390
O-RING
Выбрано товаров: 38
