Запчасти Komatsu PW95-1 ТРАНСМИССИЯ (/) ХОДОВАЯ

\0

21D-14-10020

TRANSMISSION, ASSY.

1

21D-14-11110

BEARING

2

21D-23-11970

PLUG

3

21D-23-11960

WASHER

4

21D-14-11120

COVER

5

21D-14-11130

GEAR

6

21D-14-11150

BEARING

7

21D-14-11160

SPACER

8

21D-09-83130

RING, SNAP

9

21D-14-11890

SHIM

10

21D-14-11140

SELECTOR SHAFT

11

21D-14-11180

SLIDE BLOCK

12

21D-14-11170

GEAR, RING

13

21D-14-11190

CHANGE SELECTOR

14

21D-14-11210

GUIDE, TUBE

15

21D-14-11220

GEAR

16

21D-14-11230

BEARING

17

21D-14-11240

RING

18

21D-14-11250

GEAR

19

21D-14-11260

PIN

20

21D-14-11270

PROTECTION

21

21D-14-11280

SWITCH

22

21D-14-11290

WASHER

23

21D-09-69280

O-RING

24

21D-14-11310

HOUSING

24

21D-14-11311

HOUSING

25

21D-14-11330

SENSOR, REVOLUTION

26

21D-14-11320

WASHER

27

21D-14-11340

INLET SHAFT

28

21D-14-11350

SHIM, 0.100 mm

28

21D-14-11360

SHIM, 0.200 mm

29

21D-14-11370

BEARING

30

21D-14-11380

SHIM

31

21D-14-11390

O-RING

32

21D-09-83120

RING

33

21D-14-11410

COVER

34

21D-09-74500

SPRING WASHER

35

01010-51230

BOLT
