Запчасти Komatsu PW95-1 ГИДРОЛИНИЯ (ЗАДН. ОТВАЛ С ПЕРЕДН. ОПОРА) (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

21D-60-17100

SOLENOID VALVE, ASSY.

2

21D-60-18211

KIT, GASKET

3

01252-50550

SCREW

4

21D-09-74130

SPRING WASHER

5

21D-60-17110

HOLDER, VALVE W/CASE

6

01252-40680

SCREW

7

01580-10605

NUT

8

21D-09-74440

SPRING WASHER

9

21D-62-11350

SUPPORT

10

01252-41022

SCREW

11

21D-09-74480

SPRING WASHER

12

21D-09-55140

PLUG

13

21D-09-73220

GASKET

14

21D-09-51220

UNION

15

21D-09-69910

O-RING

16

21D-09-52530

UNION

17

21D-62-13710

PIPE

18

21D-09-51660

ELBOW

19

21D-09-69910

O-RING

20

21D-09-55630

ELBOW

21

21D-09-95650

HOSE

22

21D-62-13740

PIPE

23

21D-62-13730

PIPE

24

21D-62-13720

PIPE

25

21D-09-56140

ELBOW

26

21D-09-55800

UNION

27

21D-09-56870

UNION

28

21D-09-95410

HOSE

29

21D-60-17200

VALVE, ASSY.

30

21D-60-17250

KIT, GASKET

31

21D-09-55650

ELBOW

32

21D-62-15310

UNION

33

21D-09-69910

O-RING

34

21D-62-15290

UNION

35

21D-09-69910

O-RING

36

21D-62-13640

PIPE
