Запчасти Komatsu PW95-1 ГИДРОЛИНИЯ (ЗАДН. ОПОРА) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

21D-60-17110

HOLDER, VALVE W/CASE

2

21D-60-17100

SOLENOID VALVE, ASSY.

3

21D-60-18211

KIT, GASKET

4

01252-50550

SCREW

5

21D-09-74130

SPRING WASHER

6

21D-60-18900

PLATE

7

01252-40516

SCREW

8

01252-40680

SCREW

9

21D-09-74440

SPRING WASHER

10

01580-10605

NUT

11

21D-62-11350

SUPPORT

12

01252-41022

SCREW

13

21D-09-74480

SPRING WASHER

14

21D-09-55140

PLUG

15

21D-09-73220

GASKET

16

21D-09-51220

UNION

17

21D-09-69910

O-RING

18

21D-09-55630

ELBOW

19

21D-09-52530

UNION

20

21D-62-13710

PIPE

21

21D-09-55130

PLUG

22

21D-09-73190

GASKET

23

21D-62-13670

PIPE

24

21D-62-13660

PIPE

25

21D-62-13650

PIPE

26

21D-03-11220

CONVEYOR

27

01435-00825

BOLT

28

21D-09-68180

HOSE-CLAMP

29

01435-00625

BOLT

30

21D-09-57450

UNION

31

21D-62-13680

PIPE

32

21D-62-13690

PIPE

33

21D-09-57280

ELBOW

34

21D-09-95420

HOSE

35

21D-09-95410

HOSE

36

21D-09-51660

ELBOW

37

21D-09-69910

O-RING

38

21D-09-55630

ELBOW

39

21D-09-51220

UNION

40

21D-09-69910

O-RING

41

21D-60-17200

VALVE, ASSY.

42

21D-60-17250

KIT, GASKET

43

21D-62-15290

UNION

44

21D-09-69910

O-RING

45

21D-62-15290

UNION

46

21D-09-69910

O-RING

47

21D-09-55650

ELBOW

48

21D-62-13640

PIPE
