Запчасти Komatsu PW95-1 МОТОР ХОДА (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

21D-60-15100

TRAVEL MOTOR, ASSY.

1

21D-60-15700

ROTARY GROUP, ASSY.

2

21D-60-15730

RING, SNAP

3

21D-60-15740

GASKET

4

21D-60-15750

O-RING

5

21D-60-15720

RING, SNAP

6

21D-60-15710

RING, NUT

7

21D-60-15770

SCREW

8

21D-60-15760

SPRING

9

21D-60-15450

SPRING GUIDE 8.6 mm

9

21D-60-15460

SPRING GUIDE 8.7 mm

9

21D-60-15470

SPRING GUIDE 8.8 mm

9

21D-60-15480

SPRING GUIDE 8.9 mm

9

21D-60-15490

SPRING GUIDE 9.0 mm

9

21D-60-15510

SPRING GUIDE 9.1 mm

9

21D-60-15520

SPRING GUIDE 9.2 mm

9

21D-60-15530

SPRING GUIDE 9.3 mm

9

21D-60-15540

SPRING GUIDE 9.4 mm

10

21D-60-15420

RING KIT
