Запчасти Komatsu PW95-1 УПРАВЛЯЮЩ. КЛАПАН (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

21D-64-50000

CONTROL VALVE, ASSY.

1

21D-64-11180

COVER

2

21D-64-11190

SCREW

3

01252-40512

SCREW

4

21D-64-11220

SPRING, ASSY.

5

SPOOL, 2nd BOOM

6

21D-64-11230

COVER

7

21D-64-11240

KIT, GASKET

8

WASHER

9

O-RING

10

21D-64-11100

PRESSURE RELIEF VALVE

11

21D-64-11110

KIT, GASKET

12

21D-64-11270

SPRING, ASSY.

13

SPOOL, BOOM AND ARM HIGH

14

SPOOL, BOOM SWING

15

21D-64-11140

ANTICAVITATIION VALVE

16

21D-64-11160

FLANGE, ASSY.

17

21D-64-11300

ANTICAVITATIION VALVE

18

21D-64-11310

O-RING

19

21D-64-11260

THROTTLING
