Запчасти Komatsu PW95-1 КАБИНА (/) ЧАСТИ КОРПУСА И КАБИНА

\0

21D-54-12301

OPERATOR'S CAB, ASSY.

\0

21D-54-13002

DOOR, ASSY.

1

21D-54-13110

FRAME, DOOR

2

21D-54-14890

GLASS, UPPER

3

21D-54-14910

GLASS, LOWER

4

21D-54-13120

SEAL, DOOR

5

21D-54-13420

HANDLE

6

21D-54-13410

PANEL, INNER

7

21D-54-13161

SEAL

8

21D-54-13170

SEAL, HANDLE

9

21D-54-13391

PANEL

10

01252-40870

SCREW

11

01643-30823

WASHER

12

21D-54-13240

HANDLE, EXTERNAL

13

21D-09-15750

SCREW

14

01643-30623

WASHER

15

21D-54-13550

PLUG

16

21D-09-15170

SCREW

17

21D-09-15160

SCREW

18

21D-54-13140

HINGE

19

21D-54-13150

GASKET

20

21D-54-13190

SPACER

21

21D-54-13180

RUBBER

22

01580-10806

NUT

23

21D-09-86190

COVER

24

21D-54-13340

U-BOLT

25

21D-54-13230

LOCK, BLOCK

26

21D-09-15150

SCREW

27

21D-09-74460

WASHER

28

21D-54-13280

PANEL

29

21D-09-16440

SCREW

30

21D-54-13290

WASHER

31

21D-54-13250

RUBBER

32

21D-09-15740

SCREW

33

21D-54-13260

LOCK, ASSY.

34

21D-54-13270

GASKET

35

21D-54-13310

PIN

36

21D-54-13320

PROTECTION

37

21D-54-13330

NUT

38

21D-54-13220

PIN

39

21D-54-13210

BUSHING

40

21D-09-84170

PEG

41

21D-54-14760

KIT, SIZING
