Запчасти Komatsu PW75R-2 ЗАДН. МОСТ (7/8) (WS) ХОДОВАЯ

Схема запчастей Komatsu PW75R-2 - ЗАДН. МОСТ (7/8) (WS) ХОДОВАЯ
10
11
8
42
2
7
3
15
12
1
2
14
4
18
2
13
43
17
9
16
21
22
23
5
24
25
26
6
27
28
29
19
30
20
32
32
32
30
31
34
33
31
31
31
39
35
36
37
38
40
41
A
A
B

Артикул

Название

Примечание

Количество

\0

22E-22-13010

REAR AXLE, ASSY.

1

226-22-12170

BRAKE CYLINDER, ASSY.

\1

21D-22-11310

GASKET KIT

2

226-22-12180

NUT

3

226-22-12190

PUSH-ROD

4

22E-22-12320

SUPPORT

5

22E-22-12350

SPACER

6

22E-22-12340

RING

7

226-22-12160

LEVER

8

22E-22-12360

FITTING

9

226-22-12010

LEVER

10

22E-22-11980

WASHER

10

21D-22-11220

SPACER

11

22E-22-11990

SCREW

12

226-22-11981

SLEEVE

13

226-22-11970

SCREW

14

226-22-11990

DOWEL

15

21D-22-11260

NUT

16

22E-22-12410

O-RING

17

21D-23-12490

SCREW

18

22E-23-11990

PLUG

19

226-22-11960

LEVER

20

226-22-12080

PIN

21

226-22-12110

SPRING

22

21D-22-11350

PISTON, ASSY.

23

21D-22-11290

PUSHROD

24

226-22-12120

RING, WEAR

25

226-22-12130

O-RING

26

226-22-12070

O-RING

27

226-22-12060

RING, WEAR

28

PISTON

29

226-22-12040

SPRING

30

226-22-12030

CHECK BOLT

30

DG1120703710

CHECK BOLT

31

226-22-12020

BRAKE DISK, INTERMEDIATE

32

226-22-12140

BRAKE DISK

33

21D-22-11340

PISTON, ASSY.

34

226-22-12040

SPRING

35

226-22-12060

RING, WEAR

36

226-22-12070

O-RING

37

226-22-12130

O-RING

38

226-22-12120

RING, WEAR

39

PISTON

40

21D-22-11290

PUSHROD

41

226-22-12090

LEVER

42

22E-22-11960

O-RING

43

226-22-12250

O-RING

Выбрано товаров: 47
