Запчасти Komatsu PW75R-2 ЭЛЕКТРИКА (ЛИНИЯ ДВИГАТЕЛЯ) КОМПОНЕНТЫ ДВИГАТЕЛЯ И ЭЛЕКТРИКА

1

22E-06-11272

WIRING HARNESS

2

22E-06-11551

COVER

3

226-06-11330

KNOB

4

22E-06-12130

BRACKET

5

21D-09-15230

SCREW

6

22E-09-13120

WASHER

7

22E-06-11640

RELAY HOLDER

8

22E-06-11670

RELAY

9

22E-06-11570

FUSE BOX

10

22E-06-11580

COVER

11

22E-06-11590

FUSE 30A

11

22E-06-11620

FUSE 50A

11

22E-06-11610

FUSE 40A

12

22E-09-13120

SPRING WASHER

13

21D-09-21430

NUT

14

YM129211-77290

TIMER

15

YM129100-77910

RELAY

16

22E-06-11360

BRACKET

17

DIODE

18

01010-51020

BOLT

19

01643-31032

WASHER

20

22E-06-11691

SUPPORT

21

21D-06-12360

HOSE-CLAMP

22

22E-06-12360

BRACKET

23

21D-06-12670

WIRING HARNESS, REAR

24

21D-06-11370

REAR LIGHT, ASSY.

25

01580-10605

NUT

26

21D-09-73840

WASHER

27

21D-06-11570

BULB 21W

28

21D-06-11580

BULB 7W

29

7861-92-3320

TEMPERATURE SENSOR

30

01010-51025

BOLT

31

37A-01-11430

WASHER

32

226-06-11130

HOSE-CLAMP

33

21D-09-81700

COLLAR

34

21D-06-11980

CABLE

35

01010-50614

BOLT

36

21D-09-73490

SPRING WASHER

37

226-06-11440

CLAMP

38

21D-09-16450

SCREW

39

01010-50820

BOLT

40

01643-30823

SPRING WASHER

41

01010-50816

BOLT

42

22E-06-12430

SUPPORT

43

01010-50816

BOLT

44

01643-30823

SPRING WASHER
