Запчасти Komatsu PW75R-2 МАРКИРОВКА МАРКИРОВКА

Схема запчастей Komatsu PW75R-2 - МАРКИРОВКА МАРКИРОВКА
25
24
23
22
27
33
9
19
1
8
21
7
29
29
28
18
28
20
25
24
12
16
31
30
11
15
26
18
6
32
20
14
20
28
3
4
2
10
5
17
13
a
a
b
b
c
c
d
d

Артикул

Название

Примечание

Количество

\0

22E-98-11301

MARK PLATE KIT

1

21D-98-12660

MARK PLATE, KOMATSU

2

21D-98-11150

PLATE, SAFETY, RADIATOR CAP

3

21D-98-11180

PLATE, SAFETY, ENGINE AIR FILTER

4

21D-98-11170

PLATE, SAFETY FUEL FILTER

5

21D-98-11190

PLATE, SAFETY, ENGINE OIL FILTER

6

21D-98-12040

PLATE, SAFETY, ELECTRIC SOCKET

7

21D-98-11240

PLATE, SAFETY, DO NOT OPEN ENGINE HOOD

8

21D-98-11160

PLATE, DIMENSION

9

21D-98-12020

PLATE, SAFETY, EMERGENCY EXIT

10

21D-98-12050

PLATE, SAFETY, HYDRAULIC OIL FILTER

11

21D-98-11230

PLATE, SAFETY, HYDRAULIC OIL

12

21D-98-11220

PLATE, SAFETY, FUEL

13

21D-98-11210

PLATE, READ MANUAL

14

22E-98-11310

PLATE, PW75R

15

22E-98-11230

PLATE, HYDRAULIC OIL LEVEL

16

226-98-11160

PLATE CONTROL

17

226-98-11170

MARK PLATE, LUBRIFICATION

18

21D-98-12630

PLATE, UTILITY

19

22E-98-11110

PLATE, LWA 100

20

21D-98-11860

PLATE, ANCHOR POINTS

21

22E-98-11320

PLATE, PW75R

22

22E-98-11120

PLATE, LPA 77

23

21D-98-12610

MARK PLATE, KOMATSU

24

21D-98-11120

MARK PLATE, ARM DIMENSION

25

37A-98-11140

MARK PLATE, KOMATSU

26

22E-98-11280

MARK PLATE, HAMMER - ROTATING AND CUTTING SHOVEL

27

22E-98-11180

PLATE, DO NOT LITF MORE THAN 1000 kg

27

21D-98-11280

OPERATING PLATE (ONLY WITH EQUIPMENT)

27

21D-98-12440

PLATE, LIFTING CAPACITY (WITH 2-PIECE BOOM)

28

21D-98-11420

PLATE, MAX. SPEED 20 km/h (GERMANY)

28

22E-98-11650

PLATE, MAX. SPEED 30 km/h (GERMANY)

29

21D-06-11380

REFLEX REFLECTOR

\29

22E-98-11600

MARK PLATE KIT REFLEX REFLECTOR (ONLY FOR ITALY)

30

22E-98-11260

REFLEX REFLECTOR, LATERAL, R.H.

31

21D-98-11380

REFLEX REFLECTOR, FRONT, UPPER

32

21D-98-11390

REFLEX REFLECTOR, FRONT, LOWER

33

22E-98-11270

REFLEX REFLECTOR, LATERAL, L.H.

Выбрано товаров: 38
