Запчасти Komatsu PW75R-2 ЦИЛИНДР РУКОЯТИ(ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

707-01-0S600

ARM CYLINDER, ASSY.

2

721-58-60590

PISTON ROD

3

707-76-50940

BUSHING

4

01010-81465

BOLT

5

705-17-04980

WASHER

6

01310-00820

DOWEL

7

707-27-95220

CYLINDER HEAD

8

707-36-95120

PISTON

9

707-13-95090

CYLINDER

10

04260-00635

BALL

11

707-71-91280

DOWEL

12

707-71-60100

PIN

13

707-71-34010

THRUST WASHER

14

707-71-70790

BUSHING

15

707-87-14070

PLUG

16

07750-01628

SPRING

17

707-83-13010

PIN

18

07179-12074

RING, WEAR

19

707-52-90360

PACKING ROD

20

707-75-60110

RING, WEAR

21

707-44-95911

PACKING ROD

22

707-99-27740

KIT, GASKET

23

GASKET

24

RING, WEAR

25

O-RING

26

GASKET

27

O-RING

28

GASKET

29

GASKET

30

GASKET

31

RING

32

RING, WEAR

33

RING

34

O-RING

35

O-RING

36

22E-61-12321

PIPE

37

22E-61-12310

PIPE

38

02892-03018

O-RING

39

01252-70825

SCREW

40

21D-09-73690

WASHER

41

21D-09-89140

GREASE NIPPLE
